Kia Optima II (2005-2008) diagnosis vss input on input ground Wiring diagram
This page shows the only wiring diagram for the component.diagnosis vss input on input ground, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram diagnosis vss input on input ground (1 of 1)
1 2 3 4 5 6 7 8 SOLENOID CTRL SOLENOID CTRL
1 N-03
1 Q-01
2.4L
B-01
BLK WIRE
BRN WIRE
C-01
CRUISE CONTROL UNIT (AT RIGHT REAR CORNER OF ENGINE COMPARTMENT)
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DIAGNOSIS VSS INPUT ON INPUT GROUND
ELECTRONIC TIME, ALARM CONTROL SYSTEM (ETACS)
EPS FUSE
EPS SOLENOID (ON POWER STEERING RACK HYDRAULIC CONTROL UNIT)
EPS UNIT (BEHIND LOWER CENTER OF DASH)
HOT IN ON
I-01
INSTRUMENT CLUSTER
JB-08 POWER DISTRIBUTION SYSTEM
JB-09
JB-10
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
M/T A/T
SHORT CONNECTOR SC-02
SPEED SENSOR (ON TOP OF TRANSAXLE)
SPEEDOMETER
WHT WIRE
WHT/BLK WIRE
Go to component -> Electronic power steering circuit, early production -> DIAGNOSIS VSS INPUT ON INPUT GROUND
