Kia Optima II (2005-2008) cruise control system headlights system Wiring diagram
This page shows the only wiring diagram for the component.cruise control system headlights system, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control system headlights system (1 of 1)
A/T LCD ILLUMINATION
ABS INDICATOR
AIR BAG INDICATOR
ANTI-LOCK BRAKES SYSTEM
ANTI-LOCK BRAKES SYSTEM HEADLIGHTS SYSTEM
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRAKE INDICATOR
BRN WIRE
BRN/ORG WIRE
CHARGE INDICATOR
CHECK INDICATOR
CLUSTER FUSE
CRUISE CONTROL SYSTEM HEADLIGHTS SYSTEM
CRUISE INDICATOR
D/CLOCK FUSE
DOOR INDICATOR
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM ELECTRONIC POWER STEERING SYSTEM
FRONT FOG INDICATOR
FUEL GAUGE
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START JUNCTION BLOCK (JB) (BEHIND LEFT SIDE OF DASH) A/BAG IND FUSE
ILLUMINATION
INSTRUMENT CLUSTER
JB-10
JB-11
JOINT CONNECTOR JC-06
LEFT TURN INDICATOR
LOW FUEL INDICATOR
MCU
MODE
OIL PRESSURE INDICATOR
ORG/ WIRE
PNK WIRE
POWER SUPPLY
RED WIRE
RESET+
RIGHT TURN INDICATOR
SEAT BELT INDICATOR
SHORT CONNECTOR SC-06
SPEEDOMETER
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TCS OFF INDICATOR
TEMP GAUGE
TRANSMISSIONS, ENGINE CONTROLS SYSTEMS
TRIP METER ODO METER
TRUNK INDICATOR
WARNING SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, early production (1 of 2) -> CRUISE CONTROL SYSTEM HEADLIGHTS SYSTEM
