Kia Optima II (2005-2008) c-01 instru- ment cluster Wiring diagram
This page shows the only wiring diagram for the component.c-01 instru- ment cluster, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram c-01 instru- ment cluster (1 of 1)
12 11 10 6 5 4 3 2 1 PNK WIRE
BLK WIRE
BLK/ORG WIRE
BLU ORG WIRE
BLU WIRE
BRN WIRE
C-01
C-01 INSTRU- MENT CLUSTER
COMB- INATION SWITCH
DIODE (UNDER LEFT SIDE OF DASH)
DRL FUSE
DRL RESISTOR (AT RIGHT FRONT OF ENGINE COMPT)
DRL UNIT (AT RIGHT FRONT SIDE OF ENGINE COMPT)
ETACS
FOG FUSE
FRONT FOG LAMP IND
FRONT FOG LAMP SWITCH
FRONT FOGLAMP RELAY
GENERATOR (2.4L)
GRN ORG/ WIRE
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
HEAD FUSE
HEAD HI FUSE
HEAD LOW FUSE
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON
ILLUM- INATION SWITCH
J/C 05
J/C 06
JB-01
JB-02
JB-03
JB-05
JB-09
JC-07
JC-08
JUNCTION BLOCK (JB) (BEHIND LEFT SIDE OF DASH)
LEFT FRONT FOGLAMP
LEFT HIGH HEAD- LAMP
LEFT LOW HEAD LAMP
LO HI PASS
LO LO HI PASS HI PASS
OFF
ORG/ WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK WIRE
RED/ORG WIRE
RIGHT FRONT FOGLAMP
RIGHT HIGH HEAD LAMP
RIGHT LOW HEAD LAMP
RIGHT TAIL FUSE
STARTING/ CHARGING SYSTEM
TAIL FUSE
TAILLAMP RELAY
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, early production with drl -> C-01 INSTRU- MENT CLUSTER
