Kia Optima II (2005-2008) burglar alarm relay Wiring diagrams
This page contains all the electrical diagrams for the component. burglar alarm relay, in which he is found in the car Kia Optima II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram burglar alarm relay (1 of 2)
2.4L
2.4L 2.7L CANISTER CLOSE VALVE
A/BAG FUSE
A/BAG IND FUSE
A/CON SWITCH FUSE
A/T
A/T M/T
AIR BAG CONTROL UNIT
AIR CON CONTROL UNIT (AUTOMATIC A/C)
AUTOMATIC A/C MANUAL A/C
BLOWER RELAY
BRN WIRE
BURGLAR ALARM RELAY
CLUSTER FUSE
COOLING FAN LOW RELAY
CRUISE CONTROL UNIT
CRUISE CONTROL UNIT WASHER MOTOR AQS
DATA LINK CONNECTOR BURGLAR ALARM RELAY
DRIVER BUCKLE SWITCH
ECM MIRROR
ENGINE CONTROL MODULE (ECM) (M/T) ENGINE/ TRANSAXLE CONTROL
ETACS
ETACS FUSE
FROM BLOWER RELAY (DIAGRAM 2 OF 5)
FROM COOLING FAN HIGH RELAY 2 (DIAGRAM 4 OF 5)
FROM HEAD FUSE (DIAGRAM 1 OF 5)
FROM IGNITION SWITCH (DIAGRAM 1 OF 5)
FUSE
GRN WIRE
HAZARD SWITCH
HIGH BLOWER RELAY AIR CON SWITCH
HOMELINK
IGNITION LOCK SWITCH
INHIBITOR SWITCH (A/T)
INSTRUMENT CLUSTER BURGLAR ALARM RELAY CLUTCH SWITCH
JB-01
JB-02
JB-03
JB-03 JB-01
JB-05
JB-09
JB-10
JB-11
JB-11 PNK WIRE
JB-14
JB-15
JOINT CONNECTOR SC-01
JOINT CONNECTOR SC-06
LEFT SEAT WARMER SWITCH
M/T
M/T A/T
MODULE (A/T)
ORG/ WIRE
PASSENGER BUCKLE SWITCH
PASSENGER PRESENCE DETECTION SENSOR
PNK JB-05 WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT SEAT WARMER SWITCH
S/HTD FUSE
SENSOR 1
SENSOR 2
SENSOR 3 SENSOR 1 SENSOR 2
SENSOR FUSE
STARTER RELAY
STOP LIGHT SWITCH
SUNROOF RELAY
T/SIG FUSE
TEMP SWITCH DIGITAL CLOCK AUTO LIGHT CONTROL UNIT (USA)
W/ B/ALARM
W/ HOMELINK
W/ IGN LOCK SWITCH
W/O B/ALARM
W/O HOMELINK
W/O IGN LOCK SWITCH
WIPER FUSE
WIPER MOTOR
WIPER RELAY
YEL WIRE
Go to component -> Power distribution circuit, early production (5 of 5) -> BURGLAR ALARM RELAY
Wiring diagram burglar alarm relay (2 of 2)
A/T
BATTERY
BATTERY GROUND
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRN/ORG WIRE
BURGLAR ALARM RELAY
E/R JUNCTION BOX
GRN WIRE
GRY WIRE
I/P JUNCTION BOX (LEFT END OF DASH) FUSE
I/P-A
ICM RELAY BOX (LEFT SIDE OF DASH)
IGN 2 FUSIBLE LINK
IGNITION LOCK SWITCH
IGNITION SWITCH
LOCK
M/T
ORG/ WIRE
PNK WIRE
SOLENOID
START MOTOR
START RELAY
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE ASSEMBLY)
W/ BURGLAR ALARM
W/O BURGLAR ALARM
WHT WIRE
WHT/BLK WIRE
Go to component -> Starting circuit, late production -> BURGLAR ALARM RELAY
