Kia Optima II (2005-2008) air con control unit Wiring diagrams
This page contains all the electrical diagrams for the component. air con control unit, in which he is found in the car Kia Optima II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
air con control unit wiring diagram (1 of 2)
2.4L
A/T
AIR CON CONTROL UNIT
AIR CON SWITCH
AUDIO
AUTO LIGHT CONTROL UNIT
AUTOMATIC A/C
BLK WIRE
BLOWER RELAY
BLOWER SWITCH
BRN WIRE
CAMSHAFT POSITION SENSOR CRANKSHAFT POSITION SENSOR KNOCK SENSOR
CIGAR LIGHTER ACCESSORY SOCKET
CLUTCH SWITCH
COMBINATION SWITCH
DIGITAL CLOCK
ENGINE/TRANSAXLE CONTROL MODULE (E/TCM) ENGINE CONTROL MODULE (ECM) (A/T) (M/T)
FLASHER UNIT
GLOVE BOX SWITCH
HIGH BLOWER RELAY
IGNITION COIL 2
IGNITION FAILURE SENSOR IGNITION COIL 1
ILLUMINATION SWITCH
INSTRUMENT CLUSTER
JOINT CONNECTOR JC-05
JOINT CONNECTOR JC-06
JOINT CONNECTOR JC-18
KEYLESS ENTRY UNIT
KNOCK SENSOR SHIELD SENSOR 2 SHIELD SENSOR 1 SHIELD
LEFT SEAT WARMER SWITCH RIGHT SEAT WARMER SWITCH
M/T
MANUAL A/C
MODE ACTUATOR
MULTI-PURPOSE CHECK CONNECTOR
NCA WIRE
ORG/ WIRE
PANEL LIGHT CONTROL SWITCH
PASSENGER PRESENCE DETECTION SENSOR AIR BAG CONTROL UNIT
POWER TRANSISTOR
REAR DEFROSTER
RIGHT FRONT DOOR KEY UNLOCK SWITCH
RIGHT FRONT DOOR LOCK MOTOR
RIGHT FRONT POWER WINDOW SWITCH
RIGHT POWER MIRROR MOTOR
RIGHT REAR DOOR LOCK MOTOR
RIGHT REAR POWER WINDOW SWITCH
TCS SWITCH
TEMPERATURE SWITCH
THERMISTOR
Go to component -> Ground distribution circuit, early production (2 of 3) -> AIR CON CONTROL UNIT
air con control unit wiring diagram (2 of 2)
A/CON FUSE
ABS 1 FUSE
ABS 2 FUSE
ABS CONTROL UNIT
ACC SOCKET
ACC SOCKET FUSE
AIR CON CONTROL UNIT
ALT FUSIBLE LINK
AUDIO
AUDIO FUSE
AUTOMATIC A/C
BATTERY
BLK WIRE
BRN WIRE
C/LIGHTER FUSE
CIGAR LIGHTER
COND FUSE
CONDENSER FAN HIGH RELAY 2
CONDENSER FAN MOTOR
COOLING FAN HIGH RELAY 2
COOLING FAN MOTOR
CRUISE CONTROL SWITCH EPS UNIT
DRL UNIT
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
EPS FUSE
FROM JOINT CONNECTOR SC-02 (DIAGRAM 3 OF 5)
FUSE
GENERATOR
HEAD FUSE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
IGNITION SWITCH
JB-01
JB-01 AIR CON SWITCH
JB-02
JB-03
JB-04
JB-05
JB-06
JB-07
JB-08
JB-09
JB-09 MANUAL A/C
JB-11
JB-16
JOINT CONNECTOR JC-05
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LOCK
MODE ACTUATOR
NCA WIRE
ON LOCK OFF
ON OFF
ORG/ WIRE
P/WINDOW FUSE
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW RELAY
RAD FUSE
RED WIRE
STARTER
STARTER RELAY
TO BLOWER FUSE (DIAGRAM 2 OF 5)
TO ETACS FUSE (DIAGRAM 5 OF 5)
TO JUNCTION BLOCK (BACK-UP FUSE) (DIAGRAM 2 OF 5)
TO JUNCTION BLOCK (START FUSE) (DIAGRAM 5 OF 5)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, early production (1 of 5) -> AIR CON CONTROL UNIT
