Kia Optima II (2005-2008) 6 58 memory power cruise control switch pnk Wiring diagram
This page shows the only wiring diagram for the component.6 58 memory power cruise control switch pnk, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 6 58 memory power cruise control switch pnk (1 of 1)
1 2 3 4 5 6 PNK WIRE
6 58 MEMORY POWER CRUISE CONTROL SWITCH PNK WIRE
B/UP FUSE
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CLOCK- SPRING
CRUISE CLUTCH PEDAL POSITION SWITCH (ABOVE CLUTCH PEDAL)
CRUISE CONTROL SWITCH (GND) BRAKE TEST SWITCH BRAKE LIGHT SWITCH
CRUISE IND
CRUISE MAIN
CRUISE SET IND
E/R JUNCTION BOX
ECU FUSE
ETC MOTOR, THROTTLE POSITION SENSOR (ON THROTTLE BODY)
GRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILL
INSTRUMENT CLUSTER
JOINT CONNECTOR
M/T
M/T A/T
MOTOR
MULTI- FUNCTION
ORG/ WIRE
PCM (LEFT REAR OF ENGINE COMPARTMENT)
PNK WIRE
PNK/BLK WIRE
RED WIRE
RESUME/ ACCEL
RIGHT CRUISE REMOCON SWITCH
SET/ COAST
STARTING/ CHARGING SYSTEM
STEERING WHEEL)
SWITCH
THROTTLE POSITION SENSOR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 2.4l, cruise control circuit, late production (1 of 2) -> 6 58 MEMORY POWER CRUISE CONTROL SWITCH PNK WIRE
