Kia Optima I facelift (2002-2005) Warning systems circuit

BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE CHIME BELL (UNDER LEFT SIDE OF DASH) CLUSTER FUSE D/CLOCK FUSE DOOR AJAR IND ELECTRONIC POWER STEERING SYSTEM ETACS FUSE ETACS MODULE GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR START IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH INSTRUMENT CLUSTER J/C 15 JB-07 JB-08 JB-09 JB-10 JB-10 JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) JB-11 JB-13 JC-16 JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH MCU ORG/ WIRE PNK WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH ROOM FUSE SC-06 SEAT BELT IND SEAT BELT SWITCH SPEED SENSOR (ON TOP OF TRANSAXLE) YEL WIRE YEL/BLK WIRE
