Back-up lamps circuit for Kia Optima I facelift (2002-2005)
Back-up lamps circuit
A/T
BACK-UP FUSE
BLK WIRE
GRN WIRE
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
JB-01 ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
JB-03
JB-06
JB-08
JB-10
JB-13
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT REAR COMBINATION LAMP LEFT BACK-UP LAMP
M/T
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RIGHT REAR COMBINATION LAMP RIGHT BACK- UP LAMP
TRANSMISSIONS SYSTEM
WHT WIRE
