Electronic power steering circuit for Kia Optima I facelift (2002-2005)

1 2 3 4 5 6 7 8 SOLENOID CTRL SOLENOID CTRL 1 N-03 1 Q-01 2.4L B-01 BLK WIRE BRN WIRE C-01 CRUISE CONTROL UNIT (AT RIGHT REAR CORNER OF ENGINE COMPARTMENT) DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DIAGNOSIS VSS INPUT ON INPUT GROUND ELECTRONIC TIME, ALARM CONTROL SYSTEM (ETACS) EPS FUSE EPS SOLENOID (ON POWER STEERING RACK HYDRAULIC CONTROL UNIT) EPS UNIT (BEHIND LOWER CENTER OF DASH) HOT IN ON I-01 INSTRUMENT CLUSTER JB-08 POWER DISTRIBUTION SYSTEM JB-09 JB-10 JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) M/T A/T SHORT CONNECTOR SC-02 SPEED SENSOR (ON TOP OF TRANSAXLE) SPEEDOMETER WHT WIRE WHT/BLK WIRE
