Anti-theft circuit for Kia Optima I facelift (2002-2005)
Anti-theft circuit
BLK WIRE
BLU WIRE
BURGLAR ALARM RELAY (ON JUNCTION BLOCK)
CLUSTER FUSE
D/CLOCK FUSE
DRL FUSE
ETACS
FUSE
GRN WIRE
HAZARD FUSE
HAZARD RELAY
HOOD SWITCH (AT RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
HOT AT ALL TIMES
HOT IN
JB-01
JB-02
JB-02 ENGINE COMPT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
JB-06
JB-09
JB-13 PNK WIRE
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEYLESS ENTRY UNIT (BEHIND LOWER CENTER OF DASH)
LEFT FRONT DOOR SWITCH RIGHT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED/ORG WIRE
RIGHT REAR DOOR SWITCH
STARTING/ CHARGING SYSTEM
TRUNK UNLOCK SWITCH JC-05
YEL WIRE
