Kia Optima I facelift (2002-2005) trunk unlock switch jc-05 Wiring diagram
This page shows the only wiring diagram for the component.trunk unlock switch jc-05, which is found in the car Kia Optima I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk unlock switch jc-05 (1 of 1)
BLK WIRE
BLU WIRE
BURGLAR ALARM RELAY (ON JUNCTION BLOCK)
CLUSTER FUSE
D/CLOCK FUSE
DRL FUSE
ETACS
FUSE
GRN WIRE
HAZARD FUSE
HAZARD RELAY
HOOD SWITCH (AT RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
HOT AT ALL TIMES
HOT IN
JB-01
JB-02
JB-02 ENGINE COMPT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
JB-06
JB-09
JB-13 PNK WIRE
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEYLESS ENTRY UNIT (BEHIND LOWER CENTER OF DASH)
LEFT FRONT DOOR SWITCH RIGHT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED/ORG WIRE
RIGHT REAR DOOR SWITCH
STARTING/ CHARGING SYSTEM
TRUNK UNLOCK SWITCH JC-05
YEL WIRE
