Kia Optima I facelift (2002-2005) tcs off ind Wiring diagram
This page shows the only wiring diagram for the component.tcs off ind, which is found in the car Kia Optima I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tcs off ind (1 of 1)
ABS 1 FUSE
ABS 2 FUSE
ABS CONTROL UNIT (AT RIGHT REAR OF ENGINE COMPARTMENT)
ABS FUSE
ABS IND.
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRAKE FLUID LEVEL SENSOR (ON BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
BRAKE IND
BRN WIRE
BRN/ORG WIRE
CLUSTER FUSE
CRUISE CONTROL SYSTEM
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT) JB-03
ENGINE CONTROL MODULE (2.7L) (BEHIND LOWER CENTER OF DASH)
GRN WIRE
GRN/BLK WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
J/C 06
JB-06
JB-11
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT FRONT WHEEL SPEED SENSOR (ON LEFT FRONT STEERING KNUCKLE)
LEFT REAR WHEEL SPEED SENSOR (ON LEFT REAR BRAKE BACKING PLATE)
MULTI-PURPOSE CHECK CONNECTOR
ORG/ WIRE
PNK WIRE
RED WIRE
SC-01
SC-06
STOP FUSE
STOPLIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
TCS OFF IND
TCS SWITCH
TRANSMISSIONS SYSTEM
WHT WIRE
