Kia Optima I facelift (2002-2005) speed sensor eps unit Wiring diagram
This page shows the only wiring diagram for the component.speed sensor eps unit, which is found in the car Kia Optima I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram speed sensor eps unit (1 of 1)
2.4L A/T
A/T CONTROL RELAY
ABS CONTROL UNIT
ATM CONTROL RELAY ENGINE/TRANSMISSION CONTROL MODULE
BLK WIRE
BRAKE FLUID LEVEL SENSOR
CONDENSER FAN HIGH RELAY 1
CONDENSER FAN LOW RELAY
COOLING FAN HIGH RELAY 1
CRUISE CONTROL UNIT
DATA LINK CONNECTOR
ENGINE COMPARTMENT FUSE/RELAY BOX
ENGINE CONTROL MODULE (ECM)
IGNITION COIL SHIELD
JB-03
SPEED SENSOR EPS UNIT
STARTER RELAY
TCM
WIPER MOTOR
Go to component -> Ground distribution circuit (3 of 3) -> SPEED SENSOR EPS UNIT
