Kia Optima I facelift (2002-2005) slide adjuster limit switch Wiring diagrams
This page contains all the electrical diagrams for the component. slide adjuster limit switch, in which he is found in the car Kia Optima I facelift (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram slide adjuster limit switch (1 of 2)
BACK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DOWN
DRIVER POWER SEAT ADJUSTER SWITCH
FOREWARD
FRONT HEIGHT ADJUSTER
HOT AT ALL TIMES
JB-12
JOINT CONNECTOR JC-15
JOINT CONNECTOR JC-16
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT GRN/BLK WIRE
LT GRN/WHT WIRE
ORG/ WIRE
P/SEAT FUSE (DRIVER)
REAR HEIGHT ADJUSTER
RECLINING ADJUSTER
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SLIDE ADJUSTER
SLIDE ADJUSTER LIMIT SWITCH
WHT/BLK WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Driver seat circuit -> SLIDE ADJUSTER LIMIT SWITCH
Wiring diagram slide adjuster limit switch (2 of 2)
BACK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DOWN
FOREWARD
FRONT HEIGHT ADJUSTER
HOT AT ALL TIMES
JB-08
JOINT CONNECTOR JC-15
JOINT CONNECTOR JC-16
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT GRN/BLK WIRE
LT GRN/WHT WIRE
ORG/ WIRE
P/SEAT FUSE (PASSENGER)
PASSENGER POWER SEAT ADJUSTER SWITCH
REAR HEIGHT ADJUSTER
RECLINING ADJUSTER
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SLIDE ADJUSTER
SLIDE ADJUSTER LIMIT SWITCH
WHT/BLK WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Passenger seat circuit -> SLIDE ADJUSTER LIMIT SWITCH
