Kia Optima I facelift (2002-2005) right power mirror heater Wiring diagram
This page shows the only wiring diagram for the component.right power mirror heater, which is found in the car Kia Optima I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right power mirror heater (1 of 1)
AIR CON CONTROL UNIT
AIR CON SWITCH
AUTOMATIC A/C
BLK WIRE
BLU WIRE
ETACS
JB-01
JB-06
JB-07
JB-10
JB-12
JOINT CONNECTOR JC-05
JOINT CONNECTOR JC-06
JOINT CONNECTOR JC-17
JOINT CONNECTOR JC-18
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT POWER MIRROR HEATER
MANUAL A/C
REAR DEFROSTER
REAR DEFROSTER RELAY
REAR HTD FUSE
RED WIRE
RIGHT POWER MIRROR HEATER
Go to component -> Defoggers circuit -> RIGHT POWER MIRROR HEATER
