Kia Optima I facelift (2002-2005) power tops system Wiring diagram
This page shows the only wiring diagram for the component.power tops system, which is found in the car Kia Optima I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power tops system (1 of 1)
BLK WIRE
BLU WIRE
COMBINATION METER
D/CLOCK FUSE
D/LOCK FUSE
DIODE (UNDER LEFT SIDE OF DASH)
DOOR
ETACS
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
JB-06
JB-07
JB-08
JB-11
JB-13
JB-14
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT OVERHEAD CONSOLE DOOR COURTESY LAMP
LEFT REAR DOOR SWITCH
LT GRN WIRE
MAP LAMP
MAP LAMP ON OFF
ORG/ WIRE
PNK WIRE
POWER TOPS SYSTEM
RIGHT DOOR COURTESY LAMP
RIGHT REAR DOOR SWITCH
ROOM FUSE
ROOM LAMP
TRUNK IND
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit, with sunroof -> POWER TOPS SYSTEM
