Kia Optima I facelift (2002-2005) left tail fuse Wiring diagrams
This page contains all the electrical diagrams for the component. left tail fuse, in which he is found in the car Kia Optima I facelift (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left tail fuse (1 of 2)
6 7 PNK WIRE
BLK WIRE
BLU WIRE
BRN/ORG WIRE
COMBINATION SWITCH ILLUMINATION SWITCH
DRL UNIT (AT RIGHT FRONT SIDE OF ENGINE COMPT)
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ETACS
GRN WIRE
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
J/C 05
J/C 15
JB-01
JB-01 ENGINE COMPARTMENT FUSE/RELAY BOX
JB-01 ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE JB-02 OF ENGINE COMPT)
JB-05
JB-06
JB-08 JB-13
JB-09
JB-13
JC-07
JC-08
JC-16
JOINT CONNECTOR SC-01
JOINT CONNECTOR SC-07
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT FRONT TURN SIGNAL, POSITION LAMP
LEFT LICENSE LAMP TAIL LAMP STOP LAMP
LEFT REAR COMBINATION LAMP
LEFT SIDE MARKER LAMP
LEFT TAIL FUSE
OFF
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
RIGHT FRONT TURN SIGNAL, POSITION LAMP
RIGHT LICENSE LAMP TAIL LAMP STOP LAMP
RIGHT REAR COMBINATION LAMP TURN LAMP
RIGHT SIDE MARKER LAMP
RIGHT TAIL FUSE
STOP FUSE
STOPLIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
TAIL FUSE
TAIL LAMP RELAY
TURN LAMP
W/ CRUISE CONTROL
W/ DRL
W/O CRUISE CONTROL
WHT WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LEFT TAIL FUSE
Wiring diagram left tail fuse (2 of 2)
AIR CON CONTROL UNIT (AUTOMATIC A/C) (UNDER CENTER OF DASH)
AIR CON SWITCH (MANUAL A/C)
ATM ILLUM
AUDIO
AUTO
AUTOMATIC A/C
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
CIGAR LIGHTER ASHTRAY ILLUM
COMBNATION SWITCH
CRUISE CONTROL SWITCH
DIGITAL CLOCK
DRL UNIT (AT RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ETACS
GLOVE BOX LAMP)
GLOVE BOX SWITCH
GRY WIRE
HAZARD SWITCH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
ILLUM- INATION SWITCH
INSTRUMENT CLUSTER
J/C 05
J/C 06
J/C-15 J/C-18
JB-01
JB-01 ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
JB-02
JB-05
JB-06
JB-07
JB-09
JB-11
JB-13
JB-14
JC-17
JOINT CONNECTOR SC-02
LEFT REAR POWER WINDOW SWITCH RIGHT FRONT POWER WINDOW SWITCH
LEFT SEAT WARMER SWITCH
LEFT SUNVISOR LAMP
LEFT TAIL FUSE
MANUAL A/C
OFF
ORG/ WIRE
PANEL LIGHT CONTROL SWITCH
PNK PNK WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT SEAT WARMER SWITCH
RIGHT SUNVISOR LAMP
RIGHT TAIL FUSE
TAIL FUSE
TAIL LAMP RELAY
TCS SWITCH (BEHIND RIGHT SIDE OF DASH)
W/ DRL
WHT WIRE
Go to component -> Instrument illumination circuit -> LEFT TAIL FUSE
