Kia Optima I facelift (2002-2005) left sunvisor lamp home link air con switch air con control unit Wiring diagram
This page shows the only wiring diagram for the component.left sunvisor lamp home link air con switch air con control unit, which is found in the car Kia Optima I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left sunvisor lamp home link air con switch air con control unit (1 of 1)
2.4L
A/T M/T
ATM CONTROL RELAY (2.4L) A/T CONTROL RELAY (2.7L)
ATM FUSE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
DIGITAL CLOCK
DRL UNIT
ECU FUSE
ENGINE/ TRANSAXLE CONTROL MODULE ENGINE CONTROL MODULE
FOG FUSE
FROM MAIN
FRONT FOGLAMP RELAY
FUEL PUMP FUSE
FUEL PUMP RELAY
GENERATOR
GRN WIRE
HEAD HI FUSE DRL FUSE
HEAD LOW FUSE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
INSTRUMENT CLUSTER
JB-01
JB-02
JB-02 (2.4L) (2.7L)
JB-03
JB-03 JB-02
JB-05
JB-06 PNK WIRE
JB-09
JB-13
JB-13 JB-11
JB-14
JOINT CONNECTOR JC-06
JOINT CONNECTOR SC-02
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT POSITION LAMP
LEFT SEAT WARMER SWITCH ATM ILLUMINATION
LEFT SIDE MARKER LAMP
LEFT SUNVISOR LAMP HOME LINK AIR CON SWITCH AIR CON CONTROL UNIT
LEFT TAIL LAMP LEFT TAIL LAMP
LH TAIL FUSE
ORG/ WIRE
PNK JB-08 WIRE
PNK PNK MANUAL A/C AUTOMATIC A/C WIRE
PNK PNK PNK PNK WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK W/O DRL WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH RIGHT FRONT POWER WINDOW SWITCH
RED WIRE
RH TAIL FUSE
RIGHT POSITION LAMP
RIGHT SEAT WARMER SWITCH CIGAR LIGHTER
RIGHT SIDE MARKER LAMP
RIGHT SUNVISOR LAMP LEFT LICENSE LAMP
RIGHT TAIL LAMP
RIGHT TAIL LAMP RIGHT LICENSE LAMP
SIREN
TAIL FUSE
TAIL LAMP RELAY
TCM (2.7L)
TCS SWITCH PANEL LIGHT CONTROL SWITCH GLOVE BOX LAMP HAZARD SWITCH
TO JUNCTION BLOCK POWER
W/ DRL
WHT WIRE
Go to component -> Power distribution circuit (3 of 5) -> LEFT SUNVISOR LAMP HOME LINK AIR CON SWITCH AIR CON CONTROL UNIT
