Kia Optima I facelift (2002-2005) left rear door switch Wiring diagrams
This page contains all the electrical diagrams for the component. left rear door switch, in which he is found in the car Kia Optima I facelift (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left rear door switch (1 of 4)
BLK WIRE
BLU WIRE
BURGLAR ALARM RELAY (ON JUNCTION BLOCK)
CLUSTER FUSE
D/CLOCK FUSE
DRL FUSE
ETACS
FUSE
GRN WIRE
HAZARD FUSE
HAZARD RELAY
HOOD SWITCH (AT RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
HOT AT ALL TIMES
HOT IN
JB-01
JB-02
JB-02 ENGINE COMPT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
JB-06
JB-09
JB-13 PNK WIRE
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEYLESS ENTRY UNIT (BEHIND LOWER CENTER OF DASH)
LEFT FRONT DOOR SWITCH RIGHT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED/ORG WIRE
RIGHT REAR DOOR SWITCH
STARTING/ CHARGING SYSTEM
TRUNK UNLOCK SWITCH JC-05
YEL WIRE
Go to component -> Anti-theft circuit -> LEFT REAR DOOR SWITCH
Wiring diagram left rear door switch (2 of 4)
BLK WIRE
BLU WIRE
COMBINATION METER
D/CLOCK FUSE
D/LOCK FUSE
DIODE (UNDER LEFT SIDE OF DASH)
ETACS
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
JB-06
JB-08
JB-11
JB-13
JB-14
JB-14 JB-07
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT DOOR COURTESY LAMP
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
MAP LAMP
OFF
OFF DOOR
ORG/ WIRE
PNK WIRE
RIGHT DOOR COURTESY LAMP
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
ROOM FUSE
ROOM LAMP
TRUNK IND
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit, without sunroof -> LEFT REAR DOOR SWITCH
Wiring diagram left rear door switch (3 of 4)
BLK WIRE
BLU WIRE
COMBINATION METER
D/CLOCK FUSE
D/LOCK FUSE
DIODE (UNDER LEFT SIDE OF DASH)
DOOR
ETACS
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
JB-06
JB-07
JB-08
JB-11
JB-13
JB-14
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT OVERHEAD CONSOLE DOOR COURTESY LAMP
LEFT REAR DOOR SWITCH
LT GRN WIRE
MAP LAMP
MAP LAMP ON OFF
ORG/ WIRE
PNK WIRE
POWER TOPS SYSTEM
RIGHT DOOR COURTESY LAMP
RIGHT REAR DOOR SWITCH
ROOM FUSE
ROOM LAMP
TRUNK IND
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit, with sunroof -> LEFT REAR DOOR SWITCH
Wiring diagram left rear door switch (4 of 4)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
CHIME BELL (UNDER LEFT SIDE OF DASH)
CLUSTER FUSE
D/CLOCK FUSE
DOOR AJAR IND
ELECTRONIC POWER STEERING SYSTEM
ETACS FUSE
ETACS MODULE
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
INSTRUMENT CLUSTER
J/C 15
JB-07
JB-08
JB-09
JB-10
JB-10 JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
JB-11
JB-13
JC-16
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
MCU
ORG/ WIRE
PNK WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
ROOM FUSE
SC-06
SEAT BELT IND
SEAT BELT SWITCH
SPEED SENSOR (ON TOP OF TRANSAXLE)
YEL WIRE
YEL/BLK WIRE
Go to component -> Warning systems circuit -> LEFT REAR DOOR SWITCH
