Kia Optima I facelift (2002-2005) jb-12 Wiring diagrams
This page contains all the electrical diagrams for the component. jb-12, in which he is found in the car Kia Optima I facelift (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram jb-12 (1 of 4)
AIR CON CONTROL UNIT
AIR CON SWITCH
AUTOMATIC A/C
BLK WIRE
BLU WIRE
ETACS
JB-01
JB-06
JB-07
JB-10
JB-12
JOINT CONNECTOR JC-05
JOINT CONNECTOR JC-06
JOINT CONNECTOR JC-17
JOINT CONNECTOR JC-18
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT POWER MIRROR HEATER
MANUAL A/C
REAR DEFROSTER
REAR DEFROSTER RELAY
REAR HTD FUSE
RED WIRE
RIGHT POWER MIRROR HEATER
Go to component -> Defoggers circuit -> JB-12
Wiring diagram jb-12 (2 of 4)
BACK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DOWN
DRIVER POWER SEAT ADJUSTER SWITCH
FOREWARD
FRONT HEIGHT ADJUSTER
HOT AT ALL TIMES
JB-12
JOINT CONNECTOR JC-15
JOINT CONNECTOR JC-16
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT GRN/BLK WIRE
LT GRN/WHT WIRE
ORG/ WIRE
P/SEAT FUSE (DRIVER)
REAR HEIGHT ADJUSTER
RECLINING ADJUSTER
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SLIDE ADJUSTER
SLIDE ADJUSTER LIMIT SWITCH
WHT/BLK WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Driver seat circuit -> JB-12
Wiring diagram jb-12 (3 of 4)
6 7 PNK WIRE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
COMBINATION SWITCH
FLASHER UNIT
GRN WIRE
GRY WIRE
HAZARD FUSE
HAZARD RELAY
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
JB-06
JB-08
JB-09
JB-09 JB-13
JB-11
JB-12
JOINT CONNECTOR JC-05
JOINT CONNECTOR JC-06
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) ETACS (ON JUNCTION BLOCK)
LEFT
LEFT REAR COMBINATION LAMP TAIL
LEFT TURN INDICATOR
OFF
ON OFF
ORG/ WIRE
PNK WIRE
RIGHT
RIGHT REAR COMBINATION LAMP
RIGHT TURN INDICATOR
STOP
T/SIG FUSE
TAIL
TURN SWITCH
Go to component -> Exterior lamps circuit (2 of 2) -> JB-12
Wiring diagram jb-12 (4 of 4)
2.4L
A/T
AIR CON CONTROL UNIT
AIR CON RELAY
AIR CON SWITCH DIGITAL CLOCK INSTRUMENT CLUSTER
AIR CON SWITCH LEFT POWER MIRROR MOTOR RIGHT POWER MIRROR MOTOR
AUDIO TRUNK ROOM LAMP
AUTOMATIC A/C
BLK WIRE
BLU WIRE
CONDENSER FAN HIGH RELAY 1
CONDENSER FAN HIGH RELAY 2
COOLING FAN HIGH RELAY 1
COOLING FAN HIGH RELAY 2
CRANK ANGLE SENSOR
D/CLOCK FUSE
D/LOCK FUSE
DEFOGGER SYSTEM
DIODE
DOOR KEY HOLE ILLUMINATION
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER POWER SEAT ADJUSTER SWITCH
EGR FUSE
EGR SOLENOID
ENGINE CONTROL MODULE
ENGINE/TRANSAXLE CONTROL MODULE
ETACS
FROM FUEL PUMP
FROM INJECTOR
FUEL PUMP RELAY
FUEL/TRUNK LID SWITCH TWO TURN UNLOCK RELAY
GRN/BLK WIRE
HAZARD RELAY HAZARD SWITCH
IDLE SPEED ACTUATOR
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
JB-01
JB-03
JB-05
JB-06
JB-06 JB-08
JB-08
JB-09
JB-10
JB-11
JB-11 JB-06 JB-06
JB-12
JB-13
JB-13 JB-12 JB-14
KEYLESS ENTRY UNIT
LEFT DOOR COURTESY LAMP
M/T
MANUAL A/C
MASS AIRFLOW SENSOR (2.4L) CRANKSHAFT POSITION
ORG/ WIRE
OVERHEAD CONSOLE MAP LAMP ROOM LAMP
P/SEAT (DRIVE) FUSE
PASSENGER POWER SEAT ADJUSTER SWITCH
PNK (2.4L) (2.7L) WIRE
PNK 2.4L 2.7L 2.4L WIRE
PNK 2.7L PNK PNK WIRE
PNK PNK (2.4L) (2.7L) (2.4L) (2.7L) WIRE
PNK PNK PNK WIRE
PNK WIRE
POWER FUSE 1
POWER FUSE 2
PURGE SOLENOID VALVE CAMSHAFT POSITION SENSOR
REAR DEFROSTER (POWER ANTENNA)
REAR DEFROSTER RELAY
RED WIRE
RIGHT DOOR COURTESY LAMP
ROOM FUSE
RR HTD FUSE
SENSOR (2.7L)
SENSOR 4
SHUNT
STOP FUSE HAZARD FUSE
STOPLIGHT SWITCH
T/LID FUSE P/SEAT (PASS) FUSE ECS FUSE
TRUNK LID RELAY
W/ SUN ROOF W/O SUN ROOF
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (4 of 5) -> JB-12
