Kia Optima I facelift (2002-2005) hazard relay Wiring diagrams
This page contains all the electrical diagrams for the component. hazard relay, in which he is found in the car Kia Optima I facelift (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
hazard relay wiring diagram (1 of 2)
BLK WIRE
BLU WIRE
BURGLAR ALARM RELAY (ON JUNCTION BLOCK)
CLUSTER FUSE
D/CLOCK FUSE
DRL FUSE
ETACS
FUSE
GRN WIRE
HAZARD FUSE
HAZARD RELAY
HOOD SWITCH (AT RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
HOT AT ALL TIMES
HOT IN
JB-01
JB-02
JB-02 ENGINE COMPT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
JB-06
JB-09
JB-13 PNK WIRE
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEYLESS ENTRY UNIT (BEHIND LOWER CENTER OF DASH)
LEFT FRONT DOOR SWITCH RIGHT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED/ORG WIRE
RIGHT REAR DOOR SWITCH
STARTING/ CHARGING SYSTEM
TRUNK UNLOCK SWITCH JC-05
YEL WIRE
Go to component -> Anti-theft circuit -> HAZARD RELAY
hazard relay wiring diagram (2 of 2)
6 7 PNK WIRE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
COMBINATION SWITCH
FLASHER UNIT
GRN WIRE
GRY WIRE
HAZARD FUSE
HAZARD RELAY
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
JB-06
JB-08
JB-09
JB-09 JB-13
JB-11
JB-12
JOINT CONNECTOR JC-05
JOINT CONNECTOR JC-06
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) ETACS (ON JUNCTION BLOCK)
LEFT
LEFT REAR COMBINATION LAMP TAIL
LEFT TURN INDICATOR
OFF
ON OFF
ORG/ WIRE
PNK WIRE
RIGHT
RIGHT REAR COMBINATION LAMP
RIGHT TURN INDICATOR
STOP
T/SIG FUSE
TAIL
TURN SWITCH
Go to component -> Exterior lamps circuit (2 of 2) -> HAZARD RELAY
