Kia Optima I facelift (2002-2005) cruise control unit stop light switch Wiring diagram
This page shows the only wiring diagram for the component.cruise control unit stop light switch, which is found in the car Kia Optima I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control unit stop light switch (1 of 1)
2.4L
2.4L 2.7L CANISTER CLOSE VALVE
A/BAG FUSE
A/BAG IND FUSE
A/CON FUSE
AIR BAG CONTROL UNIT
AUTOMATIC A/C MANUAL A/C
BLOWER RELAY
BRN WIRE
BURGLAR ALARM RELAY
BURGLAR ALARM RELAY A/T
CLUSTER FUSE
COOLING FAN LOW RELAY
CRUISE CONTROL UNIT STOP LIGHT SWITCH
CRUISE CONTROL UNIT WASHER MOTOR AQS
DATA LINK CONNECTOR
DRIVER BUCKLE SWITCH
ENGINE/ CONTROL MODULE (ECM) (2.4L)
ETACS
ETACS FUSE
FROM BLOWER RELAY (DIAGRAM 2 OF 5)
FROM COOLING FAN HIGH RELAY 2 (DIAGRAM 4 OF 5)
FROM IGNITION SWITCH (DIAGRAM 1 OF 5)
FUSE
GRN WIRE
HAZARD SWITCH
HIGH BLOWER RELAY AIR CON SWITCH
HOME LINK
IGNITION LOCK SWITCH
INHIBITOR SWITCH (A/T)
INSTRUMENT CLUSTER
JB-01
JB-02
JB-03
JB-03 JB-01
JB-05
JB-09
JB-10
JB-11
JB-11 PNK WIRE
JB-14
JB-15
JOINT CONNECTOR SC-01 PNK PNK WIRE
JOINT CONNECTOR SC-06
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT SEAT WARMER SWITCH
M/T
ORG/ WIRE
PASSENGER BUCKLE SWITCH
PASSENGER PRESENCE DETECTION SENSOR
PNK JB-05 WIRE
PNK PNK PNK PNK WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT SEAT WARMER SWITCH
S/HTD FUSE
SENSOR 1
SENSOR 2
SENSOR 2 SENSOR 3 SENSOR 1
SENSOR FUSE
STARTER RELAY
SUN ROOF RELAY AIR CON CONTROL UNIT (AUTOMATIC A/C)
T/SIG FUSE
TEMP SWITCH DIGITAL CLOCK AUTO LIGHT CONTROL UNIT
W/ B/ALARM
W/ IGN LOCK SWITCH
W/O B/ALARM
W/O IGN LOCK SWITCH
WIPER FUSE
WIPER MOTOR
WIPER RELAY
YEL WIRE
Go to component -> Power distribution circuit (5 of 5) -> CRUISE CONTROL UNIT STOP LIGHT SWITCH
