Kia Optima I facelift (2002-2005) cooling fan low relay Wiring diagrams
This page contains all the electrical diagrams for the component. cooling fan low relay, in which he is found in the car Kia Optima I facelift (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cooling fan low relay (1 of 6)
A/CON COMP FUSE
AIR CON RELAY
BLK WIRE
BLU WIRE
BRN WIRE
COMPRESSOR)
COND FUSIBLE LINK
CONDENSER FAN HIGH RELAY 1
CONDENSER FAN HIGH RELAY 2
CONDENSER FAN LOW RELAY
CONDENSER FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN HIGH RELAY 1
COOLING FAN HIGH RELAY 2
COOLING FAN LOW RELAY
COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
ECM CONTROL RELAY (BEHIND RIGHT SIDE OF DASH)
EGR FUSE
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
JB-01
JB-02
JB-03
JC-07
MAIN FUSE
ORG/ WIRE
PNK WIRE
RAD FUSIBLE LINK
RED WIRE
TRIPLE SWITCH (ON TOP OF A/C RECEIVER-DRIER ASSEMBLY)
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> 2.4l, automatic a/c circuit (2 of 2) -> COOLING FAN LOW RELAY
Wiring diagram cooling fan low relay (2 of 6)
12 B-01 (B)
15 B-01 (B) 13
22 B-01 (D)
A/T
B-01 (A)
B-01 (B)
B-01 (C)
BLK WIRE
BLU WIRE
BRN WIRE
C-01 (C)
COND FUSIBLE LINK
CONDENSER FAN HIGH RELAY 1
CONDENSER FAN HIGH RELAY 2
CONDENSER FAN LOW RELAY
CONDENSER FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN HIGH RELAY 1
COOLING FAN HIGH RELAY 2
COOLING FAN LOW RELAY
COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
ECM CONTROL RELAY (BEHIND RIGHT SIDE OF DASH)
EGR FUSE
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF ENGINE)
FROM ENGINE COMPARTMENT FUSE/RELAY BOX A/C RELAY (DIAGRAM 1 OF 2)
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
JB-02
JB-03
JC-07
M/T
MAIN FUSE
ORG/ WIRE
PNK WIRE
RAD FUSIBLE LINK
RED WIRE
SHORT CONNECTOR SC-05
WHT WIRE
YEL WIRE
Go to component -> 2.4l, manual a/c circuit (2 of 2) -> COOLING FAN LOW RELAY
Wiring diagram cooling fan low relay (3 of 6)
A/CON COMP FUSE
AIR CON RELAY
BLK WIRE
BLU WIRE
BRN WIRE
COMPRESSOR)
COND FUSIBLE LINK
CONDENSER FAN HIGH RELAY 1
CONDENSER FAN HIGH RELAY 2
CONDENSER FAN LOW RELAY
CONDENSER FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN HIGH RELAY 1
COOLING FAN HIGH RELAY 2
COOLING FAN LOW RELAY
COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
EGR FUSE
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) JB-01
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
JB-01
JB-02
JB-03
JC-07
MAIN FUSE
MAIN RELAY (BEHIND RIGHT SIDE OF DASH
MID
ORG/ WIRE
PNK WIRE
RAD FUSIBLE LINK
RED WIRE
TRIPLE SWITCH (ON TOP OF A/C RECEIVER-DRIER ASSEMBLY)
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> 2.7l, automatic a/c circuit (2 of 2) -> COOLING FAN LOW RELAY
Wiring diagram cooling fan low relay (4 of 6)
A/CON COMP FUSE
AIR CON RELAY
BLK WIRE
BLU WIRE
COMPRESSOR)
COND FUSIBLE LINK
CONDENSER FAN HIGH RELAY 1
CONDENSER FAN HIGH RELAY 2
CONDENSER FAN LOW RELAY
CONDENSER FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN HIGH RELAY 1
COOLING FAN HIGH RELAY 2
COOLING FAN LOW RELAY
COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
EGR FUSE
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
JB-02
JB-03
JC-07
MAIN FUSE
MAIN RELAY (BEHIND RIGHT SIDE OF DASH
ORG/ WIRE
PNK WIRE
RAD FUSIBLE LINK
RED WIRE
THERMISTOR (BEHIND RIGHT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> 2.7l, manual a/c circuit (2 of 2) -> COOLING FAN LOW RELAY
Wiring diagram cooling fan low relay (5 of 6)
2.7L 2.4L A/T 2.4L M/T
BLK WIRE
COOLING FAN HIGH RELAY 1
COOLING FAN HIGH RELAY 2
COOLING FAN LOW RELAY
COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
EGR FUSE
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE CONTROL MODULE (2.7L, 2.4L M/T) (BEHIND LOWER CENTER OF DASH)
ENGINE CONTROLS SYSTEM (2.4L)
ENGINE/TRANSAXLE CONTROL MODULE (2.4L A/T)
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
JB-02
JB-03
JOINT CONNECTOR JC-07
RAD FUSE
RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> COOLING FAN LOW RELAY
Wiring diagram cooling fan low relay (6 of 6)
2.4L
2.4L 2.7L CANISTER CLOSE VALVE
A/BAG FUSE
A/BAG IND FUSE
A/CON FUSE
AIR BAG CONTROL UNIT
AUTOMATIC A/C MANUAL A/C
BLOWER RELAY
BRN WIRE
BURGLAR ALARM RELAY
BURGLAR ALARM RELAY A/T
CLUSTER FUSE
COOLING FAN LOW RELAY
CRUISE CONTROL UNIT STOP LIGHT SWITCH
CRUISE CONTROL UNIT WASHER MOTOR AQS
DATA LINK CONNECTOR
DRIVER BUCKLE SWITCH
ENGINE/ CONTROL MODULE (ECM) (2.4L)
ETACS
ETACS FUSE
FROM BLOWER RELAY (DIAGRAM 2 OF 5)
FROM COOLING FAN HIGH RELAY 2 (DIAGRAM 4 OF 5)
FROM IGNITION SWITCH (DIAGRAM 1 OF 5)
FUSE
GRN WIRE
HAZARD SWITCH
HIGH BLOWER RELAY AIR CON SWITCH
HOME LINK
IGNITION LOCK SWITCH
INHIBITOR SWITCH (A/T)
INSTRUMENT CLUSTER
JB-01
JB-02
JB-03
JB-03 JB-01
JB-05
JB-09
JB-10
JB-11
JB-11 PNK WIRE
JB-14
JB-15
JOINT CONNECTOR SC-01 PNK PNK WIRE
JOINT CONNECTOR SC-06
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT SEAT WARMER SWITCH
M/T
ORG/ WIRE
PASSENGER BUCKLE SWITCH
PASSENGER PRESENCE DETECTION SENSOR
PNK JB-05 WIRE
PNK PNK PNK PNK WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT SEAT WARMER SWITCH
S/HTD FUSE
SENSOR 1
SENSOR 2
SENSOR 2 SENSOR 3 SENSOR 1
SENSOR FUSE
STARTER RELAY
SUN ROOF RELAY AIR CON CONTROL UNIT (AUTOMATIC A/C)
T/SIG FUSE
TEMP SWITCH DIGITAL CLOCK AUTO LIGHT CONTROL UNIT
W/ B/ALARM
W/ IGN LOCK SWITCH
W/O B/ALARM
W/O IGN LOCK SWITCH
WIPER FUSE
WIPER MOTOR
WIPER RELAY
YEL WIRE
Go to component -> Power distribution circuit (5 of 5) -> COOLING FAN LOW RELAY
