Kia Optima I facelift (2002-2005) alt fusible link Wiring diagrams
This page contains all the electrical diagrams for the component. alt fusible link, in which he is found in the car Kia Optima I facelift (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram alt fusible link (1 of 2)
A-01 STARTER
A-05 M/T GENERATOR FR
A/T
ALT FUSIBLE LINK
BATTERY
BATTERY GROUND
BLK WIRE
BLU WIRE
CHARGE IND
CLUSTER FUSE
ECU FUSE
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (BEHIND LOWER CENTER OF DASH)
ENGINE/TRANSAXLE CONTROL MODULE (BEHIND LOWER CENTER OF DASH)
ETACS
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER
JB-01
JB-02
JB-03
JB-07
JB-09
JB-11 PNK WIRE
JB-16
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LOCK
NCA WIRE
ORG/BLK WIRE
PNK WIRE
RED WIRE
RESISTOR
SC-06
WHT WIRE
Go to component -> 2.4l, charging circuit -> ALT FUSIBLE LINK
Wiring diagram alt fusible link (2 of 2)
A/CON FUSE
ABS 1 FUSE
ABS 2 FUSE
ABS CONTROL UNIT
ACC SOCKET
ACC SOCKET FUSE
AIR CON CONTROL UNIT
AIR CON SWITCH
ALT FUSIBLE LINK
AUDIO
AUDIO FUSE
AUTOMATIC A/C
BATTERY
BLK WIRE
BRN WIRE
C/LIGHTER FUSE
CIGAR LIGHTER
COND FUSE
CONDENSER FAN HIGH RELAY 2
CONDENSER FAN MOTOR
COOLING FAN HIGH RELAY 2
COOLING FAN MOTOR
CRUISE CONTROL SWITCH EPS UNIT
DRL UNIT
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
EPS FUSE
FUSE
GENERATOR
HEAD FUSE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
IGNITION SWITCH
INTERIOR LIGHTS SYSTEM JB-08 PNK WIRE
JB-01
JB-02
JB-03
JB-04
JB-05
JB-06
JB-07
JB-09
JB-11
JB-16
JOINT CONNECTOR JC-05
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LOCK
MANUAL A/C
MODE ACTUATOR
NCA WIRE
ORG/ WIRE
P/WINDOW FUSE
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW RELAY
RAD FUSE
RED WIRE
STARTER
STARTER RELAY
TO BLOWER
TO ETACS
TO JUNCTION BLOCK
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 5) -> ALT FUSIBLE LINK
