Power door lock circuit for Kia Optima I (2000-2002)
Power door lock circuit
BLK WIRE
BLU WIRE
BLU/WHT WIRE
D/CLOCK FUSE
DOOR LOCK
DOOR LOCK SWITCH
ENGINE COMPARTMENT FUSE BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
ETACS MODULE (BEHIND CENTER OF DASH)
GRY WIRE
HOT AT ALL TIMES
JOINT CONNECTOR JC-15
JOINT CONNECTOR JC-17
JOINT CONNECTOR JC-18
LEFT FRONT DOOR KEY UNLOCK SWITCH
LEFT FRONT DOOR LOCK MOTOR
LEFT REAR DOOR LOCK MOTOR
LT BLU WIRE
LT GRN/BLK WIRE
NCA WIRE
RIGHT FRONT DOOR KEY UNLOCK SWITCH
RIGHT FRONT DOOR LOCK MOTOR
RIGHT REAR DOOR LOCK MOTOR
TAN WIRE
WHT WIRE
