Courtesy lamps circuit, with sunroof for Kia Optima I (2000-2002)
Courtesy lamps circuit, with sunroof
BLK WIRE
BLU WIRE
D/CLOCK FUSE
DOOR
ETACS MODULE
GRN/BLK WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
JB-06
JB-07
JB-08
JB-13
JB-14
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT DOOR COURT- ESY LAMP
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
MAP
OFF
ORG/ WIRE
OVERHEAD CONSOLE
PPL JB-14
RIGHT DOOR COURT- ESY LAMP
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
ROOM FUSE
ROOM LAMP
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
YEL WIRE
