Exterior lamps circuit for Kia Optima I (2000-2002)

BLK WIRE BLU WIRE BRN/WHT WIRE COMBIN- ATION SWITCH DRL UNIT MODULE (AT RIGHT SIDE ENGINE COMPT) ENGINE COMPARTMENT FUSE/RELAY BOX ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT) ETACS MODULE HIGH MOUNTED STOP LIGHT HOT AT ALL TIMES ILLUM- INATION SWITCH J/C F-14 (BEHIND LEFT SDIE OF DASH) J/C F-15 J/C-05 (BEHIND INSTRUMENT CLUSTER) J/C-15 (BELOW LEFT FRONT SEAT) JB-01 JB-01 ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT JB-02 JB-02 SIDE OF ENGINE COMPT) JB-05 JB-06 JB-08 JB-13 JB-09 JB-13 JC-07 JC-08 JUNCTION BLOCK (BEHIND LEFT SDIE OF DASH) LEFT FRONT TURN SIGNAL AND POSITION LAMP LEFT LICENSE LAMP LEFT REAR COMBINATION LAMP LEFT SIDE MARKER LAMP LEFT TAIL FUSE LT BLU WIRE OFF ORG/ WIRE PPL RIGHT FRONT TURN SIGNAL AND POSITION LAMP RIGHT LICENSE LAMP TAIL RIGHT REAR COMBINATION LAMP RIGHT SIDE MARKER LAMP RIGHT TAIL FUSE STOP FUSE STOPLIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) TAIL FUSE TAIL LAMP RELAY TAIL STOP TURN TURN STOP W/ CRUISE W/ DRL W/O CRUISE WHT WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/WHT WIRE C-01 ETACS MODULE (ON JUNCTION BLOCK) FLASHER UNIT GRN WIRE GRY WIRE HAZARD FUSE HAZARD RELAY HAZARD SWITCH HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER J/C-05 (BEHIND INSTRUMENT CLUSTER) J/C-06 (BEHIND INSTRUMENT CLUSTER) JB-06 JB-08 JB-09 JB-09 JB-13 JB-11 JB-12 JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LEFT LEFT STOP LIGHT LEFT TURN INDICATOR LT BLU WIRE MULTIFUNCTION SWITCH OFF ON OFF ORG/ WIRE PNK WIRE RIGHT RIGHT STOP LIGHT RIGHT TURN INDICATOR T/SIG FUSE TURN SWITCH
