Cooling fan circuit for Kia Optima I (2000-2002)
Cooling fan circuit
BLK WIRE
BLU WIRE
COOLING FAN HIGH RELAY 1 (ENGINE COMPART FUSE/ RELAY BOX)
COOLING FAN HIGH RELAY 2 (IN ENGINE COMPARTMENT FUSE/RELAY BOX)
COOLING FAN LOW RELAY (ENGINE COMPART FUSE/ RELAY BOX)
COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
DIODE
ENGINE COMPARTMENT FUSE/ RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) EGR FUSE
ENGINE CONTROL MODULE (BEHIND LOWER CENTER OF DASH)
GRN WIRE
HOT AT ALL TIMES
JOINT CONNECTOR JC-03
NCA WIRE
RAD FUSE
RED WIRE
WHT WIRE
YEL WIRE
