Kia Optima I (2000-2002) stop light switch Wiring diagrams
This page contains all the electrical diagrams for the component. stop light switch, in which he is found in the car Kia Optima I (2000-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram stop light switch (1 of 2)
ABS 1 FUSE
ABS 2 FUSE
ABS ACTIVE MODULE
ABS CONTROL UNIT (AT RIGHT REAR OF ENGINE COMPARTMENT)
ABS EBD IND
ABS FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
DATA LINK CONNECTOR
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (BEHIND LOWER CENTER OF DASH)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
JB-03
JB-11
JOINT CONNECTOR
JOINT CONNECTOR JC-05
JOINT CONNECTOR JC-06
LEFT FRONT WHEEL SPEED SENSOR (AT LEFT FRONT WHEEL)
LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR WHEEL)
LT BLU WIRE
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR (AT RIGHT FRONT WHEEL)
RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL)
STOP FUSE
STOP LIGHT SWITCH
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TCS IND
TCS OFF INDICATOR
TCS SWITCH
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brake circuits -> STOP LIGHT SWITCH
Wiring diagram stop light switch (2 of 2)
2.4L
2.4L 2.5L CANISTER CLOSE VALVE
A/BAG FUSE
A/CON FUSE
A/T
AIR BAG CONTROL UNIT PNK WIRE
AIR CON CONTROL UNIT (AUTO A/C)
AUTO A/C MANUAL A/C
BLOWER RELAY
BRN WIRE
BURGLAR ALARM RELAY
CLUSTER FUSE
COOLING FAN LOW RELAY
CRUISE CONTROL UNIT
CRUISE CONTROL UNIT WASHER MOTOR AQS
DIGITAL CLOCK
DRIVER BUCKLE SWITCH
ECM MIRROR
ENGINE CONTROL MODULE (ECM)
ETACS FUSE
ETACS MODULE
FROM BLOWER RELAY (DIAGRAM 2 OF 5)
FROM COOLING FAN HIGH RELAY 2 (DIAGRAM 4 OF 5)
FROM IGNITION SWITCH (DIAGRAM 1 OF 5)
FUSE
HAZARD SWITCH
HIGH BLOWER RELAY AIR CON SWITCH
IGNITION LOCK SWITCH
INHIBITOR SWITCH
INSTRUMENT CLUSTER
JB-01
JB-02
JB-03
JB-03 JB-01
JB-05
JB-05 JB-10 PNK WIRE
JB-09
JB-10
JB-11
JB-11 PNK PNK WIRE
JB-11 PNK WIRE
JB-14
JB-15
JOINT CONN G-11 (BEHIND RIGHT CENTER OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT SEAT WARMER SWITCH
M/T
PASSENGER BUCKLE SWITCH
PNK PASSENGER PRESENCE DETECTION SENSOR WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
RELAY
RIGHT SEAT WARMER SWITCH
S/HTD FUSE
SENSOR 1
SENSOR 2
SENSOR 2 SENSOR 3 SENSOR 1
SENSOR FUSE
STOP LIGHT SWITCH
SUNROOF RELAY
T/SIG FUSE
TEMP SWITCH
VIO WIRE
W/ B/ALARM
W/ IGN LOCK SWITCH
W/O B/ALARM
W/O IGN LOCK SWITCH
WIPER FUSE
WIPER MOTOR
WIPER RELAY
YEL WIRE
Go to component -> Power distribution circuit (5 of 5) -> STOP LIGHT SWITCH
