Kia Optima I (2000-2002) rear defroster relay etacs module Wiring diagram
This page shows the only wiring diagram for the component.rear defroster relay etacs module, which is found in the car Kia Optima I (2000-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear defroster relay etacs module (1 of 1)
AIR QUALITY SENSOR
AMPLIFIER
BLK WIRE
BRN WIRE
CLOCKSPRING/ COMBINATION SWITCH
COMBINATION SWITCH
CRUISE CONTROL UNIT
CRUISE REMOTE CONTROL SWITCH
DOOR KEY HOLE ILLUMINATION
DRL UNIT
ENGINE COMPARTMENT FUSE/RELAY BOX
FRONT HEIGHT ADJUSTER
HOOD SWITCH
JOINT CONNECTOR JC-05
JOINT CONNECTOR JC-07
JOINT CONNECTOR JC-08
JOINT CONNECTOR JC-15
JOINT CONNECTOR JC-17
JUNCTION BLOCK
LEFT FRONT DOOR KEY UNLOCK SWITCH
LEFT FRONT DOOR LOCK MOTOR
LEFT FRONT FOGLIGHT
LEFT HEADLIGHT
LEFT HORN
LEFT LICENSE LAMP LEFT TAILLAMP
LEFT POSITION LAMP
LEFT POWER MIRROR MOTOR
LEFT REAR DOOR LOCK MOTOR LEFT REAR POWER WINDOW SWITCH
LEFT SEAT WARMER
LEFT SIDE MARKER LAMP
LEFT SUNVISOR LAMP
LEFT TAILLAMP
LT GRN WIRE
MAP LAMP
OVERHEAD CONSOLE SUNROOF MOTOR
PASSENGER PRESENCE DETECTION SENSOR AIR BAG CONTROL MODULE INSTRUMENT CLUSTER
POWER ANTENNA FUEL TANK
POWER MIRROR SWITCH
POWER SEAT ADJUSTER SWITCH
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
REAR DEFROSTER RELAY ETACS MODULE
RIGHT FRONT FOGLIGHT
RIGHT HEADLAMP
RIGHT HORN
RIGHT LICENSE LAMP RIGHT TAILLAMP
RIGHT POSITION LAMP
RIGHT SEAT WARMER INSTRUMENT CLUSTER
RIGHT SIDE MARKER LAMP
RIGHT SUNVISOR LAMP
RIGHT TAILLLAMP TRUNK LID SOLENOID
ROOM LAMP
SEAT BELT SWITCH HIGH MOUNTED STOP LAMP
SLIDE ADJUSTER LIMIT SWITCH REAR HEIGHT ADJUSTER
SUNROOF RELAY
TRUNK UNLOCK SWITCH
W/ SUNROOF ECM MIRROR
W/O ABS
W/O SUNROOF
WHT WIRE
WIPER MOTOR RELAY COOLING FAN LOW RELAY
Go to component -> Ground distribution circuit (1 of 3) -> REAR DEFROSTER RELAY ETACS MODULE
