Kia Optima I (2000-2002) panel light control switch tcs switch glove box lamp hazard switch Wiring diagram
This page shows the only wiring diagram for the component.panel light control switch tcs switch glove box lamp hazard switch, which is found in the car Kia Optima I (2000-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram panel light control switch tcs switch glove box lamp hazard switch (1 of 1)
2.4L
2.4L, 2.5L
2.4L: ATM CONTROL RELAY 2.5L: A/T CONTROL RELAY
2.5L
A/T M/T
ATM FUSE
BRN WIRE
BRN/WHT WIRE
CIGAR LIGHTER POWER WINDOW MAIN SWITCH
DIGITAL CLOCK
DRL UNIT
ECU FUSE
ENGINE/ TRANSMISSION CONTROL MODULE ENGINE CONTROL MODULE
FOG FUSE
FROM
FRONT FOG LAMP RELAY
FUEL PUMP FUSE
FUEL PUMP RELAY
GENERATOR
HEAD HI FUSE DRL FUSE
HEAD LOW FUSE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
INSTRUMENT CLUSTER
JB-01
JB-02
JB-03
JB-05
JB-06
JB-08
JB-13
JB-13 JB-11 JB-14
JB-14
JOINT CONNECTOR JC-06 (BEHIND CENTER OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT SIDE MARKER LAMP
LEFT SUNVISOR LAMP AIR CON CONTROL UNIT AIR CON SWITCH
LEFT TAIL LAMP LEFT TAIL LAMP
LH TAIL FUSE
MANUAL A/C AUTO A/C
ORG/ WIRE
PANEL LIGHT CONTROL SWITCH TCS SWITCH GLOVE BOX LAMP HAZARD SWITCH
RED WIRE
RH TAIL FUSE
RIGHT FRONT TURN SIGNAL, POSITION LAMP
RIGHT SEAT WARMER SWITCH ATM ILLUMINATION
RIGHT SIDE MARKER LAMP
RIGHT SUNVISOR LAMP LEFT LICENSE LAMP
RIGHT TAIL LAMP
RIGHT TAIL LAMP RIGHT LICENSE LAMP
SIREN
TAIL FUSE
TAIL LAMP RELAY
TO JUNCTION BLOCK POWER
TRANSMISSION CONTROL MODULE (2.5L)
VIO WIRE
WHT WIRE
Go to component -> Power distribution circuit (3 of 5) -> PANEL LIGHT CONTROL SWITCH TCS SWITCH GLOVE BOX LAMP HAZARD SWITCH
