Kia Optima I (2000-2002) left front door switch Wiring diagrams
This page contains all the electrical diagrams for the component. left front door switch, in which he is found in the car Kia Optima I (2000-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front door switch (1 of 2)
BLK WIRE
BLU WIRE
D/CLOCK FUSE
DOOR
ETACS MODULE
GRN/BLK WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
JB-06
JB-07
JB-08
JB-13
JB-14
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT DOOR COURT- ESY LAMP
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LT BLU WIRE
MAP LAMP
OFF
ON OFF
ORG/ WIRE
PPL
RIGHT DOOR COURT- ESY LAMP
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
ROOM FUSE
ROOM LAMP
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
YEL WIRE
Go to component -> Courtesy lamps circuit, without sunroof -> LEFT FRONT DOOR SWITCH
Wiring diagram left front door switch (2 of 2)
BLK WIRE
BLU WIRE
D/CLOCK FUSE
DOOR
ETACS MODULE
GRN/BLK WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
JB-06
JB-07
JB-08
JB-13
JB-14
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT DOOR COURT- ESY LAMP
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
MAP
OFF
ORG/ WIRE
OVERHEAD CONSOLE
PPL JB-14
RIGHT DOOR COURT- ESY LAMP
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
ROOM FUSE
ROOM LAMP
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
YEL WIRE
Go to component -> Courtesy lamps circuit, with sunroof -> LEFT FRONT DOOR SWITCH
