Kia Optima I (2000-2002) hood switch front right door key unlock switch Wiring diagram
This page shows the only wiring diagram for the component.hood switch front right door key unlock switch, which is found in the car Kia Optima I (2000-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hood switch front right door key unlock switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BURGLAR ALARM RELAY
CHECK CONNECTOR
D/CLOCK FUSE
DRL FUSE
ENGINE COMPT FUSE/ RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ETACS MODULE
FRONT LEFT DOOR KEY UNLOCK SWITCH
FUSE
GRN WIRE
HAZARD FUSE
HAZARD RELAY
HOOD SWITCH FRONT RIGHT DOOR KEY UNLOCK SWITCH
HOT AT ALL TIMES
HOT IN START
J/C 05
JB-01
JB-02 LT
JB-06
JB-09
JC-08 JC-18
JC-17
JUNCTION BLOCK (BEHIND LEFT SIDE DASH)
KEYLESS ENTRY CONTROL MODULE (LOWER CENTER OF DASH)
LEFT REAR DOOR LOCK MOTOR
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
PPL
RED WIRE
RIGHT REAR DOOR LOCK MOTOR
SIREN
STARTING/ CHARGING SYSTEM
TRUNK UNLOCK SWITCH
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit -> HOOD SWITCH FRONT RIGHT DOOR KEY UNLOCK SWITCH
