Kia Optima I (2000-2002) front door switch lh Wiring diagram
This page shows the only wiring diagram for the component.front door switch lh, which is found in the car Kia Optima I (2000-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front door switch lh (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CHIME BELL (UNDER LEFT SIDE OF DASH)
CLUSTER FUSE
D/CLOCK FUSE
ETACS FUSE
ETACS MODULE
FRONT DOOR SWITCH LH
FRONT DOOR SWITCH RH
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
INSTRUMENT CLUSTER SYSTEM
JB-07
JB-08
JB-13
JC-15 (UNDER DRIVER'S SEAT)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR F-14 (BEHIND LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
REAR DOOR SWITCH LH
REAR DOOR SWITCH RH
ROOM FUSE
SEAT BELT SWITCH
YEL WIRE
Go to component -> Warning system circuits -> FRONT DOOR SWITCH LH
