Kia Optima I (2000-2002) condenser fan high relay 1 condenser fan low relay starter relay Wiring diagram
This page shows the only wiring diagram for the component.condenser fan high relay 1 condenser fan low relay starter relay, which is found in the car Kia Optima I (2000-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram condenser fan high relay 1 condenser fan low relay starter relay (1 of 1)
2.4L
2.5L
A/T CONTROL RELAY
ABS CONTROL MODULE
ABS CONTROL UNIT
ATM CONTROL RELAY
BLK WIRE
BRAKE FLUID LEVEL SENSOR VEHICLE SPEED SENSOR
CONDENSER FAN HIGH RELAY 1 CONDENSER FAN LOW RELAY STARTER RELAY
CONDENSER FAN LOW RELAY CONDENSER FAN HIGH RELAY 1
COOLING FAN HIGH RELAY
CRUISE CONTROL UNIT
ENGINE COMPARTMENT FUSE/RELAY BOX
ENGINE CONTROL MODULE (ECM)
ENGINE/TRANSMISSION CONTROL MODULE
EPS UNIT
IGNITION COIL SHIELD
STARTER RELAY
TOP OF ENGINE)
TRANSMISSION CONTROL MODULE (TCM)
WHT WIRE
WIPER MOTOR
Go to component -> Ground distribution circuit (3 of 3) -> CONDENSER FAN HIGH RELAY 1 CONDENSER FAN LOW RELAY STARTER RELAY
