Kia Optima I (2000-2002) auto cruise ground battery tps sig Wiring diagram

12 13 14 15 16 PNK PNK WIRE 7 8 PNK WIRE A/C SIG A/C SYSTEM A/T CONTROL RELAY (AT BASE OF CRASH PAD CENTER SUPPORT BRACKET) ATM SOLENOID ASSEMBLY (IN TRANSAXLE VALVE BODY) AUTO CRUISE GROUND BATTERY TPS SIG B-01 BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CRUISE CONTROL SYSTEM DCC R INPUT 3 INPUT L INPUT ENGINE/TRANSAXLE CONTROL MODULE (E/TCM) (BEHIND LOWER CENTER OF DASH) FLASH SOURCE FTP SENS GRN WIRE GROUND BATTERY GROUND BATTERY KS SIG GRY WIRE HOT AT ALL TIMES ENGINE COMPARTMENT FUSE/RELAY BLOCK ATM FUSE INSTRUMENT CLUSTER SYSTEM J/C (BEHIND FRONT OF CENTER CONSOLE) JB-03 K-LINE DIAG LR OD LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE OIL TEMP SENSOR ORG/ WIRE ORG/BLK WIRE P INPUT D INPUT PULSE GEN A PULSE GEN B PNK WIRE PNK 1 2 WIRE PNK B-01 WIRE PNK WIRE PULSE GENERATOR "A" (ON TOP OF TRANSAXLE) PULSE GENERATOR "B" (ON TOP OF TRANSAXLE) RED WIRE RED/BLK WIRE STARTING/ CHARGING SYSTEM TAN WIRE TRANSAXLE RANGE SWITCH (ON TOP OF TRANSAXLE) UD N INPUT 2 INPUT STOP LAMP SW O/T VIO WIRE VSS INPUT WHT WIRE YEL WIRE YEL/WHT WIRE
