Kia Niro I facelift (2019-2022) p/wdw relay control Wiring diagrams

This page contains all the electrical diagrams for the component. p/wdw relay control, in which he is found in the car Kia Niro I facelift (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram p/wdw relay control (1 of 3)

Wiring diagram p/wdw relay control for Kia Niro I facelift (2019-2022) (1 of 3)

Get access

BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE DOWN GRN WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE HIGH IND HOT AT ALL TIMES I/P-C IGPM ILL IPS CONTROL MODULE LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH LEFT REAR SEAT WARMER SWITCH LOCK LOW IND MEMORY PWR MOTOR ORG/ WIRE P/WDW RELAY CONTROL P/WINDOW LH FUSE P/WINDOW RH FUSE PNK WIRE PNK/BLK WIRE POWER WINDOW LH RELAY POWER WINDOW RH RELAY RED WIRE RIGHT REAR POWER WINDOW MOTOR SEATS SYSTEM WHT WIRE WINDOW SWITCH SIGNAL YEL WIRE

Go to component -> Power windows circuit, w/ ims w/ driver/passenger auto up/down & safety power windows (2 of 3) -> P/WDW RELAY CONTROL

Wiring diagram p/wdw relay control (2 of 3)

Wiring diagram p/wdw relay control for Kia Niro I facelift (2019-2022) (2 of 3)

Get access

AUTO DOWN AUTO UP UP BLK WIRE BLU WIRE BRN WIRE DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN GRN WIRE GRY WIRE HOT AT ALL TIMES I/P-C IGPM ILL IPS CONTROL MODULE LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH OFF ORG/ WIRE P/WDW RELAY CONTROL P/WINDOW LH FUSE P/WINDOW RH FUSE PASSENGER POWER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW LH RELAY POWER WINDOW MAIN SWITCH POWER WINDOW RH RELAY POWER WINDOW SWITCH RED WIRE RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH WHT WIRE WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component -> Power windows circuit, w/o ims w/ driver auto up/down & safety power windows (1 of 2) -> P/WDW RELAY CONTROL
