Kia Niro I facelift (2019-2022) plug-in hybrid Wiring diagrams

A/BAG IND FUSE A/C CONTROL MODULE A/C FUSE AMBIENT TEMP SENS (+) BLK WIRE BLOWER RLY CTRL BLU WIRE BLU/BLK WIRE BRN WIRE BRN/ORG WIRE CAN HIGH CAN LOW CLIMATE CAN HIGH CLIMATE CAN LOW COMP PWR - COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DETENT DRV MODE ACT DEF DRV MODE ACT F/B DRV MODE ACT VENT DRV TEMP ACT COOL DRV TEMP ACT F/B DRV TEMP ACT WARM E/R JUNCTION BLOCK ELECTRONIC A/C COMPRESSOR (LOWER LEFT SIDE OF ENGINE) ENGINE CONTROLS SYSTEM EVAPORATOR SENS (+) GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR START HYBRID INVERTER HYBRID POWER CONTROL UNIT (HPCU) I/P-A I/P-E I/P-F IGPM ILL IN-CAR TEMPERATURE SENSOR INTAKE ACT F/B INTAKE ACT FRE INTAKE ACT REC INTERLOCK - LEAK CURRENT AUTO CUT DEVICE LH PHOTO SENS (-) MAIN BATT - MEM PWR MEMORY 1 FUSE MODULE 5 FUSE MULTI FUSE 2 NCA WIRE ON INPT ON INPUT ON/START INPUT ORG/ WIRE ORG/BLK WIRE P-CAN HIGH P-CAN LOW PLUG-IN HYBRID PNK WIRE PTC HEATER PTC HEATER 1 FUSE PTC HEATER 1 RELAY PTC HEATER 2 FUSE PTC HEATER 2 RELAY PTC RLY CTRL 1 PTC RLY CTRL 2 PWM IN RED WIRE RH PHOTO SENS (-) RR DEFOGGER IND RR DEFOGGER SW SENS GND SENS PWR WHT WIRE YEL WIRE

A/C PRESSURE TRANSDUCER APT GND APT SIG BATTERY C/FAN RELAY BLK WIRE BLU WIRE BLU/WHT WIRE BMS BLOWER MOTOR BMS CONTROL MODULE BRN WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM COOLING FAN CTRL COOLING FAN FUSE COOLING FAN RELAY E/R JUNCTION BLOCK ENG CTRL RLY CTRL ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR (EHRS) EWP FUSE FEEDBACK GRN WIRE GROUND GRY WIRE H-CAN HIGH H-CAN LOW HOT AT ALL TIMES MAIN BATTERY PACK (PLUG-IN HYBRID) MAIN BATTERY PACK BLOWER FAN MULTI FUSE 1 NCA WIRE ORG/ WIRE P-CAN HIGH P-CAN LOW PLUG-IN HYBRID PLUG-IN HYBRID, HYBRID PNK WIRE PNK/BLK WIRE POWER PWR RED WIRE RED/BLU WIRE RED/WHT WIRE RLY CTRL SENS PWR SPEED SUB BATTERY PACK (PLUG-IN HYBRID) SUB BATTERY PACK BLOWER FAN WTS GND WTS SIG YEL WIRE

ACTIVE AIR FLAP UNIT LH (FRONT OF VEHICLE) ACTIVE AIR FLAP UNIT RH (FRONT OF VEHICLE) BATTERY C/FAN FUSE BLK WIRE BLU WIRE BMS ASSEMBLY BMS CONTROL MODULE BRN WIRE COMPUTER DATA LINES SYSTEM E/R-A E/R-D ELECTRIC WATER PUMP (ENGINE) ELECTRIC WATER PUMP (HEV) ENGINE CONTROL RELAY EWP FUSE FEEDBACK GRN WIRE GRY WIRE H-CAN HIGH H-CAN LOW HOT AT ALL TIMES HOT IN ON OR START I/P-A I/P-C I/P-D I/P-F IGPM LEAK CURRENT AUTO CUT DEVICE MEM PWR MEMORY 2 FUSE MODULE 8 FUSE NCA WIRE ON/START INPUT ORG/ WIRE P-CAN HIGH P-CAN LOW PCB BLOCK PLUG-IN HYBRID PNK WIRE RED WIRE RLY CTRL SENSOR 2 FUSE SPEED WHT WIRE YEL WIRE

B/UP LAMP FUSE BACKUP BLK WIRE BLU WIRE BRN WIRE DCT 4 FUSE E/R JUNCTION BLOCK E/R-D ELECTRO- CHROMIC MIRROR GRN WIRE HOT IN ON OR START I/P-A IGPM LEFT BACKUP LAMP NCA WIRE ON/START INPUT ORG/ WIRE PCB BLOCK PLUG-IN HYBRID PNK WIRE RED WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT BACKUP LAMP SIG TCM YEL WIRE

AUTO BCM BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN TRANSCEIVER COMPUTER DATA LINES SYSTEM DIMMER CIRCUIT GND SIG 1 GRY WIRE INSTRUMENT CLUSTER LAMP SWITCH LEFT HEADLAMP LEFT TURN IND LIGHT LOW HEAD- MICOM MULTI- FUNCTION SWITCH NCA WIRE OUT PLUG-IN HYBRID PNK WIRE RED WIRE RED/ORG WIRE RIGHT HEADLAMP RIGHT TURN IND SWITCH OUT TAIL TAIL LAMP TAIL ON IND TURN LAMP TURN LEFT TURN RIGHT TURN SIGNAL W/ LED W/O LED WHT WIRE

AJAR AUTO LIGHT, PHOTO SENSOR B-CAN HI B-CAN LO B-CAN TRANSCEIVER IC BCM BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL DR LK DR UNLK DRIVER DOOR LOCK ACTUATOR DRIVER'S DOOR E/R-C GRN WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HORN (HIGH) HORN (LOW) HORN FUSE HORN RELAY HORN SYSTEM HOT AT ALL TIMES ICM RELAY BOX LOCK SWITCH MCU NCA WIRE NOT USED PASSENGER'S DOOR PCB BLOCK PLUG-IN HYBRID PNK/BLK WIRE RED WIRE SECURITY IND SECURITY LED TWO TURN UNLOCK RELAY UNLOCK SWITCH WHT WIRE YEL WIRE

ANTENNA COIL BLK WIRE BLU WIRE BRN WIRE BRN/ORG WIRE C-CAN CLUSTER FUSE COIL COMPUTER DATA LINES SYSTEM EMS GRN WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-F IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH IGPM IMMO DATA LINE IMMO IND IMMOBILIZER MODULE (UPPER LEFT SIDE OF DASH) IND INPUT SIG INTERFACE INSTRUMENT CLUSTER K LINE K-LINE SIG INTERFACE MEM PWR MICOM MICRO CONTROLLER NCA WIRE ON/ST INPUT ORG/ WIRE PDM 2 FUSE PDM 3 FUSE PLUG-IN HYBRID PNK IGN 1 WIRE PNK WIRE PWR SUPPLY REGULATION RED WIRE SERIAL SIG INTERFACE TRANSCEIVER/ TRANSPONDER TRANSPONDER READER IC WHT WIRE YEL WIRE

+B CPU ANT GND ANT PWR B+ LOAD BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE C-CAN CENTER REAR OF LUGGAGE COMPT) CLUSTER FUSE COMPUTER DATA LINES SYSTEM EXTERNAL BUZZER GRN WIRE GROUND DISTRIBUTION SYSTEM HOT IN ON OR START I/P-F IGN 1 IGPM IMMO IND INSTRUMENT CLUSTER MICOM NCA WIRE ORG/ WIRE PLUG-IN HYBRID PNK WIRE PWR RED WIRE RED/BLK WIRE SMART KEY ANTENNA 1 SMART KEY ANTENNA 2 SMART KEY BUMPER ANTENNA SMART KEY CONTROL MODULE (RIGHT SIDE OF DASH) SMART KEY TRUNK ANTENNA SSB ILL PWR TRANSCEIVER/ WHT WIRE WHT/BLK WIRE YEL WIRE

AMP B-CAN HIGH B-CAN LOW BCM (RIGHT SIDE OF HVAC UNIT) BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BRN WIRE C-CAN TRANSCEIVER CLUSTER FUSE COMPUTER DATA LINES SYSTEM FRONT PDW SENSOR PWR GND SIG 1 GRN WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN ON OR START HYBRID, PLUG-IN HYBRID I/P-F IGPM ILL INSTRUMENT CLUSTER LEAK CURRENT AUTOCUT DEVICE LEFT FRONT PARKING DISTANCE WARNING SENSOR LEFT FRONT PARKING DISTANCE WARNING SENSOR (CENTER) LEFT REAR PARKING DISTANCE WARNING SENSOR LEFT REAR PARKING DISTANCE WARNING SENSOR (CENTER) LID 1 LID 2 LID 3 LT GRN/BLK WIRE MEMORY FUSE MICOM MODULE 3 FUSE PARKING DISTANCE WARNING SWITCH PDW SENSOR GND PDW SWITCH IND PDW SWITCH MODE PLUG-IN HYBRID PNK PDW SENSOR PWR WIRE PNK WIRE REAR PDW SENSOR PWR RED WIRE RED/WHT WIRE REG RIGHT FRONT PARKING ASSIST WARNING SENSOR RIGHT FRONT PARKING DISTANCE WARNING SENSOR (CENTER) RIGHT REAR PARKING DISTANCE WARNING SENSOR RIGHT REAR PARKING DISTANCE WARNING SENSOR (CENTER) RVM SWITCH SPEAKER UPPER COVER CONSOLE SWITCH WHT WIRE WHT/BLK WIRE YEL WIRE

AJAR AUTO LIGHT, PHOTO SENSOR B-CAN HI B-CAN LO B-CAN TRANSCEIVER IC BCM BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL DR LK DR UNLK DRIVER DOOR LOCK ACTUATOR DRIVER'S DOOR E/R-C GRN WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HORN (HIGH) HORN (LOW) HORN FUSE HORN RELAY HORN SYSTEM HOT AT ALL TIMES ICM RELAY BOX LOCK SWITCH MCU NCA WIRE NOT USED PASSENGER'S DOOR PCB BLOCK PLUG-IN HYBRID PNK/BLK WIRE RED WIRE SECURITY IND SECURITY LED TWO TURN UNLOCK RELAY UNLOCK SWITCH WHT WIRE YEL WIRE
