Kia Niro I facelift (2019-2022) pdf sig Wiring diagrams
This page contains all the electrical diagrams for the component. pdf sig, in which he is found in the car Kia Niro I facelift (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pdf sig (1 of 2)
ACTIVE HYDRAULIC BOOSTER 1 FUSE
ACTIVE HYDRAULIC BOOSTER 2 FUSE
ACTIVE HYDRAULIC BOOSTER 3 FUSE
AUTO HOLD SWITCH
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE LIGHT SWITCH
BRAKE PEDAL MODULE
BRAKE TEST SWITCH
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DRIVER DOOR SWITCH SIG
E/R JUNCTION BLOCK
E/R-D
ESC OFF SWITCH
FL SIG
FL VCC
FR SIG
FR VCC
GND 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INTEGRATED BRAKE ACTUATION UNIT
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
MEMORY POWER
MOTOR GND
MOTOR POWER
NCA WIRE
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB BLOCK
PDF GND
PDF POWER
PDF SIG
PDT GND
PDT POWER
PDT SIG
PNK WIRE
RED WIRE
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
RL SIG
RL VCC
RR SIG
RR VCC
SHIELD
WHEEL SENS O/P (FR)
WHT WIRE
YEL WIRE
Go to component -> Anti lock brake circuit, w/ epb (1 of 3) -> PDF SIG
Wiring diagram pdf sig (2 of 2)
ACTIVE HYDRAULIC BOOSTER 1 FUSE
ACTIVE HYDRAULIC BOOSTER 2 FUSE
ACTIVE HYDRAULIC BOOSTER 3 FUSE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE LIGHT SWITCH
BRAKE PEDAL MODULE
BRAKE TEST SWITCH
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DRIVER DOOR SWITCH SIG
E/R JUNCTION BLOCK
E/R-D
ESC OFF SWITCH
FL SIG
FL VCC
FR SIG
FR VCC
GND 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INTEGRATED BRAKE ACTUATION UNIT
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
MEMORY POWER
MOTOR GND
MOTOR POWER
NCA WIRE
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PARKING BRAKE SWITCH
PCB BLOCK
PDF GND
PDF POWER
PDF SIG
PDT GND
PDT POWER
PDT SIG
PNK WIRE
RED WIRE
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
RL SIG
RL VCC
RR SIG
RR VCC
SHIELD
WHEEL SENS O/P (FR)
WHT WIRE
YEL WIRE
Go to component -> Anti lock brake circuit, w/o epb (1 of 2) -> PDF SIG
