Kia Niro I facelift (2019-2022) pass mode act vent Wiring diagram
This page shows the only wiring diagram for the component.pass mode act vent, which is found in the car Kia Niro I facelift (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass mode act vent (1 of 1)
A/C CONTROL MODULE
AUTO DEFOG ACT CLOSE
AUTO DEFOG ACT F/B
AUTO DEFOG ACT OPEN
AUTO DEFOG SENSOR
AUTO DEFOGGER ACTUATOR
AUTO DEFOGGER SENSOR
BCM
BELT IND
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
COOLING FAN MOTOR
DUCT SENS (FLOOR)
DUCT SENS (VENT)
DUCT SENSOR (FLOOR)
DUCT SENSOR (VENT)
GRN WIRE
GRY WIRE
HAZARD IND
NCA WIRE
ORG/ WIRE
PAB IGN
PAB OFF LAMP
PASS MODE ACT DEF
PASS MODE ACT F/B
PASS MODE ACT VENT
PASS SEAT
PASS SEAT BELT IND
PASS TEMP ACT COOL
PASS TEMP ACT F/B
PASS TEMP ACT WARM
PASSENGER MODE ACTUATOR
PASSENGER TEMPERATURE ACTUATOR
PNK WIRE
PWR
RED WIRE
SIG
SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 5) -> PASS MODE ACT VENT
