Kia Niro I facelift (2019-2022) low tell-tale Wiring diagrams
This page contains all the electrical diagrams for the component. low tell-tale, in which he is found in the car Kia Niro I facelift (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
low tell-tale wiring diagram (1 of 2)
B+2 FUSE
B+3 FUSE
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
FAN
FOOT PARKING BRAKE SWITCH
GRN WIRE
GRY WIRE
H/LAMP HI FUSE
H/LAMP HI RELAY
HIGH BEAM SOLENOID
HIGH LOW
HOT AT ALL TIMES
INTEGRATED BRAKE ACTUATION UNIT
LDM
LEFT HEADLAMP (W/ LED)
LEFT HEADLAMP (W/O LED)
LOW TELL-TALE
MULTI FUSE 1
NCA WIRE
PARKING BRAKE
RED WIRE
RIGHT HEADLAMP (W/ LED)
RIGHT HEADLAMP (W/O LED)
SHIELD
SWITCH
W/ LED
W/O LED
WHT WIRE
YEL WIRE
Go to component -> Autolamps circuit (2 of 3) -> LOW TELL-TALE
