Kia Niro I facelift (2019-2022) headlamp high switch in Wiring diagrams
This page contains all the electrical diagrams for the component. headlamp high switch in, in which he is found in the car Kia Niro I facelift (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram headlamp high switch in (1 of 2)
AUTO
AUTO LIGHT SENSOR
AUTO LIGHT SENSOR GND
AUTO LIGHT SENSOR POWER
AUTO LIGHT SENSOR SIG
B-CAN HIGH
B-CAN LOW
BCM (RIGHT SIDE OF HVAC UNIT)
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
DIMMER
FOG LAMP SWITCH INPUT
FOG LAMP SWITCH SIG
FRONT FOG
GND (BCM)
GRY WIRE
HEAD (LOW)
HEAD LAMP HIGH SWITCH OUT
HEADLAMP HIGH SWITCH IN
HEADLAMP LOW BACKUP SWITCH OUT
INPUT
LIGHT SWITCH OUT
LIGHT SWITCH SIG
MULTI- FUNCTION SWITCH
ON/START
PASS
PLUG-IN HYBRID
POWER DISTRIBUTION SYSTEM
PWR GND
REAR FOG
RED WIRE
SIG GND
TAIL
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
WIPER, LIGHT GND
YEL WIRE
Go to component -> Autolamps circuit (3 of 3) -> HEADLAMP HIGH SWITCH IN
