Kia Niro I facelift (2019-2022) drl turn led lamp gnd sig Wiring diagram
This page shows the only wiring diagram for the component.drl turn led lamp gnd sig, which is found in the car Kia Niro I facelift (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drl turn led lamp gnd sig (1 of 1)
ARISU CONTROL
B+2 FUSE
B+3 FUSE
B-CAN
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DRL TURN LED LAMP GND SIG
E/R JUNCTION BLOCK
FRT T/SIG LH
FRT T/SIG RH
FRT TAIL\DRL LH
FRT TAIL\DRL RH
GATEWAY
GRN WIRE
GRN/BLK WIRE
HAZARD SW
HAZARD SW IND
HMSL
HOT AT ALL TIMES
I/P-A
I/P-B
I/P-C
I/P-D
I/P-E
I/P-G
IGPM
IPS CONTROL
IPS CONTROL MODULE
LOW HIGH
MODULE 1 FUSE
MULTI FUSE 1
NCA WIRE
PNK WIRE
REAR COMBI GND
RED WIRE
RED/ORG WIRE
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
RR T/SIG LH
RR T/SIG RH
RR TAIL EXT LH
RR TAIL EXT RH
STOP LAMP
STOP LP LH
STOP LP RH
TAIL LAMP
TURN LAMP
W/ LED
W/O LED
YEL WIRE
Go to component -> Exterior lamps circuit (4 of 5) -> DRL TURN LED LAMP GND SIG
