Kia Niro I (2016-2019) left audio remote control switch steering wheel Wiring diagram
This page shows the only wiring diagram for the component.left audio remote control switch steering wheel, which is found in the car Kia Niro I (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left audio remote control switch steering wheel (1 of 1)
A/C CONTROL MODULE
A/V, NAVIGATION HEAD UNIT
AUDIO
AUX, USB JACK
B+ LOAD
B+3 FUSE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CLOCK- SPRING
CONSOLE SWITCH
DETENT
E/R JUNCTION BLOCK
FRONT AIR VENTILATION SEAT CONTROL MODULE
FRONT SEAT WARMER CONTROL MODULE
FUEL FILLER SWITCH
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
ILL
LEFT AUDIO REMOTE CONTROL SWITCH STEERING WHEEL
LT GRN WIRE
MULTI FUSE 1
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT STEERING WHEEL REMOTE CONTROL SWITCH
SHIFT LEVER INDICATOR
SMART KEY CONTROL MODULE
SSB ILL GND
SSB ILL PWR
START/STOP BUTTON SWITCH
UPPER COVER CONSOLE SWITCH
USB CHARGER
W/ NAVIGATION W/O NAVIGATION W/ AIR VENTILATION SEAT W/O AIR VENTILATION SEAT
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> LEFT AUDIO REMOTE CONTROL SWITCH STEERING WHEEL
