Kia Niro I (2016-2019) hsg resolver Wiring diagram

AIR CONDITIONING SYSTEM BATT GND BATT PWR BLK WIRE BLK/ORG WIRE BLU/ORG WIRE BRAKE SW 1 (BRAKE LAMP) (PINS: 17 TO 37 NOT USED) BRAKE SW 2 (SW INPUT) CLUTCH ACTUATOR (HEV) CLUTCH ACTUATOR FUSE COMP PWR - COMPUTER DATA LINES SYSTEM E/R JUNCTION BLOCK E/R-A GRN WIRE H-CAN HIGH H-CAN LOW (PINS: 83 TO 86 NOT USED) HOT AT ALL TIMES HOT IN ON OR START HPCU HSG RESOLVER HSG RESOLVER (-) (PINS: 89 TO 92 NOT USED) HSG RESOLVER SENS 1 HSG RESOLVER SENS 2 HSG RESOLVER SENS 3 HSG RESOLVER SENS 4 HSG RESOLVER SHIELD HSG TEMP SENS GND HSG TEMP SENS SHIELD (PINS: 45 TO 47 NOT USED) HSG TEMP SENS SIG HYBRID INVERTER HYBRID MOTOR HYBRID POWER CONTROL UNIT HYBRID STARTER, GENERATOR MOTOR L-CAN HIGH L-CAN LOW LOW VOLTAGE DC-DC CONVERTER MAIN FUSE MEMORY PWR MEMORY PWR (PINS: 7 TO 14 NOT USED) MTR RESOLVER (-) MTR RESOLVER SENS 1 MTR RESOLVER SENS 2 MTR RESOLVER SENS 3 MTR RESOLVER SENS 4 MTR RESOLVER SENS SHIELD PNK ON/START INPUT WIRE MTR TEMP SENS GND MTR TEMP SENS SHIELD (PINS: 51 TO 61 NOT USED) MTR TEMP SENS SIG MULTI FUSE 1 MULTI FUSE 2 MULTI FUSE 3 ON/START INPUT ORG/ WIRE P-CAN HIGH P-CAN LOW PCB BLOCK PNK WIRE PWR RLY ASSEMBLY (-) PWR-U PWR-V PWR-W RED WIRE RESOLVER RESOLVER SENS 1 RESOLVER SENS 2 RESOLVER SENS 3 RESOLVER SENS 4 RESOLVER SHIELD START SIG (PINS: 39 TO 41 NOT USED) TEMP SENS GND TEMP SENS SHIELD TEMP SENS SIG WHT WIRE
