Kia Niro I (2016-2019) hpcu hybrid power control unit Wiring diagram
This page shows the only wiring diagram for the component.hpcu hybrid power control unit, which is found in the car Kia Niro I (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hpcu hybrid power control unit (1 of 1)
APS 1 GROUND
APS 1 POWER
APS 1 SIGNAL
APS 2 GROUND
APS 2 POWER
APS 2 SIGNAL
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE LIGHT SW
BRAKE SW 1 (BRAKE LAMP)
BRAKE SW 2 (SW INPUT)
BRAKE TEST SW
BRN WIRE
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM
CRUISE ON/OFF
DOWN
E/R-A
ETC OUTPUT (+)
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HPCU HYBRID POWER CONTROL UNIT
ILL
LT GRN WIRE
MEMORY POWER
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB BLOCK
PNK WIRE
RED WIRE
RIGHT STEERING REMOTE CONTROL SWITCH
SCC
SET- RES+
STEERING WHEEL)
TPS 1 SIGNAL
TPS 2 SIGNAL
TPS GROUND
TPS POWER
TRIP
UP TRIP
VEHICLE SPD SENS INPUT
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (1 of 3) -> HPCU HYBRID POWER CONTROL UNIT
