Kia Niro I (2016-2019) eco power meter Wiring diagram
This page shows the only wiring diagram for the component.eco power meter, which is found in the car Kia Niro I (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eco power meter (1 of 1)
A/V, NAVIGATION HEAD UNIT
AUDIO
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
ECO POWER METER
ETC MOTOR, THROTTLE POSITION SENSOR
GRN WIRE
GROUND SIGNAL 1
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-F
IGPM
INSTRUMENT CLUSTER
LEAK CURRENT AUTO CUT DEVICE
MEMORY 1 FUSE
MICOM
MOTOR
ORG/ WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
REG
SPEED OUT
SPEEDOMETER
THROTTLE POSITION SENSOR
TRIP
TRIP (+) TRIP (-)
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 3) -> ECO POWER METER
