Kia Niro I (2016-2019) battery fuse, latch relay block Wiring diagrams
This page contains all the electrical diagrams for the component. battery fuse, latch relay block, in which he is found in the car Kia Niro I (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram battery fuse, latch relay block (1 of 3)
A/V, NAVIGATION HEAD UNIT
AC INVERTER MODULE
AC INVERTER MODULE SHIELD
AFLS UNIT
AMP
AUDIO
AUX, USB JACK
BATTERY FUSE, LATCH RELAY BLOCK
BATTERY GND
BLK WIRE
BLK/ORG WIRE
BMS ASSEMBLY
BMS BLOWER MOTOR
BMS CONTROL MODULE
BURGLAR ALARM HORN
HOOD SWITCH
HPCU
HYBRID POWER CONTROL UNIT
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
INTEGRATED BRAKE ACTUATION UNIT
LOW VOLTAGE DC-DC CONVERTER
MAIN BATTERY SAFETY PLUG (SIGNAL)
MDPS UNIT
MIC SHIELD
MULTI-PURPOSE CHECK CONNECTOR
NCA WIRE
PTC HEATER
RIGHT HEADLAMP
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT REAR DOOR LOCK ACTUATOR
SPEED SENSOR
TCM
TOP OF ENGINE)
WASHER LEVEL SENSOR
WASHER MOTOR
Go to component -> Ground distribution circuit (1 of 7) -> BATTERY FUSE, LATCH RELAY BLOCK
Wiring diagram battery fuse, latch relay block (2 of 3)
ACTIVE HYDRAULIC BOOSTER 1 FUSE
ACTIVE HYDRAULIC BOOSTER 2 FUSE
AUXILIARY BATTERY SWITCH
B+ RELAY (LATCH TYPE)
B+2 FUSE
B+3 FUSE
B+4 FUSE
B+5 FUSE
BATTERY FUSE, LATCH RELAY BLOCK
BLK WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
BLU/WHT WIRE
BMS ASSEMBLY
BMS B+ FUSE
BMS CONTROL MODULE
CLUTCH ACTUATOR (HEV)
CLUTCH ACTUATOR FUSE
COOLING FAN FUSE
COOLING FAN RELAY
CURRENT SENSOR
GRN WIRE
GRN/WHT WIRE
INTEGRATED BRAKE ACTUATION UNIT
INVERTER FUSE
LOW VOLTAGE DC-DC CONVERTER HYBRID POWER CONTROL UNIT
MAIN FUSE
MDPS FUSE
MDPS UNIT
MULTI FUSE 1
MULTI FUSE 2
MULTI FUSE 3
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
ORG/ WIRE
PTC HEATER 1 FUSE
PTC HEATER 1 RELAY
PTC HEATER 2 FUSE
PTC HEATER 2 RELAY
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
RED/WHT WIRE
RELAY S/W FUSE
RLY CTRL (RESET)
RLY CTRL (SET)
RLY ON SIG
TO AC INVERTER MODULE (DIAGRAM 10 OF 11)
TO DCT 1 FUSE (DIAGRAM 11 OF 11)
TO IGNITION SWITCH (DIAGRAM 4 OF 11)
TO IGPM (DIAGRAM 2 OF 11)
TO IGPM (DIAGRAM 3 OF 11)
TO PCB BLOCK (DIAGRAM 3 OF 11)
TO PDM 1 (ACC) RELAY (DIAGRAM 5 OF 11)
TO POWER OUTLET 1 FUSE (DIAGRAM 7 OF 11)
W/ SMART KEY W/O SMART KEY
WHT WIRE
WIPER RR FUSE
WIPER RR RELAY
YEL WIRE
Go to component -> Power distribution circuit (1 of 11) -> BATTERY FUSE, LATCH RELAY BLOCK
Wiring diagram battery fuse, latch relay block (3 of 3)
AUXILIARY BATTERY SWITCH
B+ RELAY (LATCH TYPE)
BATTERY FUSE, LATCH RELAY BLOCK
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BMS ASSEMBLY
BMS B+ FUSE
BMS CONTROL MODULE
BRN WIRE
C-CAN
CHARGE IND
COMPUTER DATA LINES SYSTEM
CURRENT SENSOR
FROM MAIN BATTERY SAFETY PLUG (DIAGRAM 5 OF 5)
GND SIG 3
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
MAIN FUSE
MAIN NEGATIVE RELAY
MAIN POSITIVE RELAY
MICOM
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER RELAY ASSEMBLY
PRE CHARGE RELAY
PRE-CHARGE RESISTOR
RED WIRE
RED/WHT WIRE
RELAY S/W FUSE
TO MAIN BATTERY MODULE 1 (DIAGRAM 4 OF 5)
TRANSCEIVER/
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l hybrid, hybrid control circuit (3 of 5) -> BATTERY FUSE, LATCH RELAY BLOCK
