Driver"s memory seat circuit for Kia K900 II (2018-2022)

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER CCS MODULE DRIVER CUSHION MTR SIG DRIVER HEADREST MOTOR (FWD/BWD) DRIVER HEADREST MOTOR (UP/DOWN) DRIVER HEADREST MTR SIG DRIVER LUMBAR SUPPORT UNIT DRIVER POWER SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER POWER SEAT SWITCH DRIVER REAR HEIGHT MOTOR DRIVER REAR HEIGHT MTR SIG DRIVER RECLINING MTR SIG DRIVER SEAT WARMER CONTROL MODULE DRIVER SLIDE MTR SIG DRIVER TILT MOTOR DRIVER TILT MTR SIG ECU B+ ECU GND GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ICU JUNCTION BLOCK ICU-A ICU-D LEAK CURRENT AUTO CUT DEVICE LIN BUS MEMORY 1 FUSE MEMORY POWER MODULE 7 FUSE NCA WIRE ON/START INPUT ORG/ WIRE P/SEAT (DRV)1 FUSE P/SEAT (DRV)2 FUSE PNK WIRE PWR GND RED WIRE RED/BLK WIRE SENS SPLY W/ CCS W/O CCS WHT WIRE WHT/BLK WIRE YEL WIRE

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CAN TX COMPUTER DATA LINES SYSTEM DAU FUSE DRIVER CUSHION MOTOR DRIVER CUSHION MTR BWD DRIVER CUSHION MTR FWD DRIVER DOOR MODULE DRIVER HEADREST MTR BWD DRIVER HEADREST MTR DOWN DRIVER HEADREST MTR FWD DRIVER HEADREST MTR UP DRIVER IMS SWITCH DRIVER POWER SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER REAR HEIGHT MTR DOWN DRIVER REAR HEIGHT MTR UP DRIVER RECLINING MOTOR DRIVER RECLINING MTR BWD DRIVER RECLINING MTR FWD DRIVER SLIDE MOTOR DRIVER SLIDE MTR BWD DRIVER SLIDE MTR FWD DRIVER TILT MTR DOWN DRIVER TILT MTR UP GRY WIRE HEALTH CARE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-A ICU-D ILL IMS SW I/P LEAK CURRENT AUTO CUT DEVICE MCU MODULE 5 FUSE NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RED/BLK WIRE REGULATOR RELAY ENERGIZED SET- SW 1 SW 2 VBAT VCC WHT WIRE WHT/BLK WIRE YEL WIRE
