Kia K900 II (2018-2022) mirr control ind Wiring diagram
This page shows the only wiring diagram for the component.mirr control ind, which is found in the car Kia K900 II (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirr control ind (1 of 1)
B-CAN HIGH
B-CAN LOW
BCW IND
BLK WIRE
BLK/ORG WIRE
BLU/BLK WIRE
BLU/ORG WIRE
CAN TX
COMPUTER DATA LINES SYSTEM
DAU FUSE
DEFOGGER
DRIVER DOOR CAMERA
DRIVER DOOR MODULE
ECM MIRROR
FOLDING MOTOR
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT W/
ICU JUNCTION BLOCK
ICU-A
ICU-D
IMS SW I/P
LEAK CURRENT AUTO CUT DEVICE
LIN TX
MCU
MIRR CONTROL IND
MIRR DOWN
MIRR LEFT
MIRR RIGHT
MIRR SELECT
MIRR SELECT LEFT IND
MIRR SELECT RIGHT IND
MIRR UP
MIRRORS SYSTEM
MODULE 5 FUSE
NAVIGATION SYSTEM
NCA WIRE
OEC
OUTSIDE MIRROR CONTROL (IMS)
PASSENGER POWER OUTSIDE MIRROR
POWER
PUDDLE LAMP
RED WIRE
REGULATOR
SIGNAL
SMART CONNECTOR
TURN LAMP
VBAT
VCC
VIDEO+
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> MIRR CONTROL IND
